38
You can load your vehicle at a ramp in two possible ways:
1. You can use a separate dock plate. Make sure that
sufficient space for tail lift exists under the ramp (see figure
on the left)!
2. You can use the tail lift itself as dock plate at a ramp. Make
sure that the platform edge overlaps the ramp at least 150
mm (see figure on the left).
Note: The maximum permissible load must not be exceeded.
The tail lifts are equipped with a float mode. The float mode is
a safety feature. When the vehicle lowers itself during loading,
the float mode causes the platform to automatically yield and
reposition itself. This does not apply to column lifts.
The float mode does not function during unloading. You must
manually lower the platform. Thus you prevent a gap between
platform and ramp where you could trip.
min. 150 mm
