57
Opening the Platform
Loosen the platform interlock (if present).
Press the pushbutton (29) and simultaneously move the
joystick (27) to the left (direction of travel right) or to the right
(direction of travel left) and hold them in this position until
the platform has reached the horizontal operating position.
Lowering the Platform
Press the pushbutton (29) and simultaneously move the
joystick downward and hold them in this position until the
platform is adjusted flush to the ground.
After the platform has touched the ground it tilts and adjusts
to the ground.
Lifting the Platform
Press the pushbutton (29) and simultaneously move the
joystick (27) upward and hold them in this position until the
platform has reached the vehicle loading floor height.
The platform tilts to the horizontal or preset position before
it is lifted.
Closing the Platform
Press the pushbutton (29) and simultaneously move the
joystick (27) to the right (direction of travel right) or to the left
(direction of travel left) and hold them in this position until
the platform is completely closed.
Close the platform interlock (if present).
