FOREST CRANE PALMS 840
V 1.03 EN  2012 Palmse Mehaanikakoda LLC 31
Pos
Code
Part name
Qty
1
840100001
Housing of FD-legs
1
2
840100002
FD-leg outrigger left
1
3
840100003
FD-leg outrigger right
1
4
840100004
Column
1
5
840100005
Main boom
1
6
840100006
Ext.boom
1
7
840100007
Puller 1
1
8
840100008
Puller 2
1
9
840100009
Puller 3
1
10
840100010
Puller 4
1
11
840100011
Cylinder cover
1
12
840100012
Cylinder shaft on column
1
13
840100013
Shaft of column/main boom junction
1
14
840100014
Cylinder shaft on main boom
2
15
840100015
Shaft of wide angle joint
2
16
840100016
Shaft of main/ext. boom joint
1
17
840100017
Shaft of ext.boom puller
2
18
840100018
Slider of cylinder cover
5
19
840100019
Gear rack
2
20
840100020
Housing of slewing device
1
21
840100021
Locking nut
2
22
840100022
Supportive bolt
2
23
840100023
Supportive slider
2
24
840100024
Cover
1
25
840100025
Tube clamp curved
3
26
840100026
Tube clamp stright
2
27
840100027
Hose clamp
1
28
840100028
Washer of wide angle joint
4
29
840100029
Distance hoop
4
30
840100030
Main boom tube 1
6
31
840100031
Main boom tube 2
2
32
840100032
Hollows 90 x 450+65
4
33
840100033
Cylinder of main boom
1
34
840100034
Ext.boom cylinder
1
35
840100035
FD-leg cylinder L
1
36
840100036
FD-leg cylinder R
1
37
840100037
Shaft of hanger
2
