FOREST CRANE PALMS 840
V 1.03 EN  2012 Palmse Mehaanikakoda LLC 32
Pos
Code
Part name
Qty
38
840100038
Grapple shaft 25x93
1
39
840100039
Shaft of support leg cylinder, lower
2
40
840100040
Shaft of support leg cylinder, upper
2
41
840100041
Shaft of support leg joint
2
42
840100042
Hanger
1
43
840100043
Rotator
1
44
840100044
Grapple 22
1
45
840100045
Nut M100x2
1
46
840100046
Double-row spherical roller bearing 3022E
1
47
840100047
Bronze slide bearing 50-55x50 WB800
8
48
840100048
Bronze slide bearing 170-175x60 WB800
1
49
840100049
Bronze slide bearing 50-55x30 WB800
2
50
840100050
Bronze slide bearing 50-55x30 WL-WB800
2
51
840100051
Polupac-gasket DBM 275196
4
52
840100052
ISC O-ring 30-3 NBR
2
53
840100053
ISC O-ring 38-2 NBR
2
54
840100054
Lubrication nipple M6
13
55
840100055
Locking hoop ø170x4.0 DIN 472
1
56
840100056
Locking hoop ø25x1.2 DIN 471
2
57
840100057
Cotter pin ø10x50 DIN 148
4
58
840100058
Hex head bolt M8x20 DIN 933
18
59
840100059
Hex head bolt M10x80 DIN 931
2
60
840100060
Hex head bolt M12x25 DIN 933
2
61
840100061
Hex head bolt M12x35 DIN 933
10
62
840100062
Socket head cap bolt M12x45 DIN
24
63
840100063
Flat socket head cap bolt M12x20 DIN 7991
4
64
840100064
Socket head cap bolt M16x30 DIN
1
65
840100065
Hex head bolt M24x110 DIN 931
8
66
840100066
Nylon lock nut M10 DIN 985
2
67
840100067
Nylon lock nut M12 DIN 985
3
68
840100068
Nylon lock nut M20 DIN 985
2
69
840100069
Nylon lock nut M24 DIN 985
8
70
840100070
Nylon lock nut M30 DIN 985
2
71
840100071
Nylon lock nut M36 DIN 985
4
72
840100072
Washer M8 DIN 125
18
73
840100073
Washer M10 DIN 125
2
