16
Connecting your HD-STB
4. Display Mode Change
This HD-STB supports simultaneous video output of HD and SD.
For HD output, it required display mode setting.
This HD-STB supports Native 1080i/50Hz, Native 720p/50Hz and Native 576p/50Hz.
The factory default is Native 1080i/50Hz.
For change the output display mode, please check up your TV support display mode. To
determine which resolution your HD input television supports, please consult the
Television's user manual.
For change display mode, please follow below procedure.
1) Press front panel UP and DOWN button simultaneously.
2) Press front panel UP or DOWN button for desired display mode.
The OSD will show selected mode and LED indicator will blink.
3) Press front panel UP and DOWN button simultaneously again to change
selected Display Mode.
STB Connection to 576p/720p/1080i High Definition Display
Most Plasma and LCD display and some CRT television with HD input(s) fall into this
category. To determine which resolution(s) your display support, consult the user
manual for your display device.
STB Connection to Standard Definition Display
Most existing 4:3 televisions fall into this Category.
For optimum SD picture quality, we recommend S-Video connection. If your TV sets
dose not supports S-Video then you should use the composite (CVBS) Video input.
(Yellow cinch socket)
576i 15.625 KHz
S-Video and CVBS
STB Video Output Video Output Scan Frequency STB Video Connection
STB Video Output
1080i
720p
576p
Video Output Scan Frequency
28.125 KHz
37.500 KHz
31.250 KHZ
STB Video Connection
HD-YPbPr
HDMI
