4.4 Print site file
Use the PROG submenu to print the data in a site file
that was set up and saved as described in chapter 1,
programming site data. To print a site file, refer to figure 16 of
Appendix A, menu maps and complete the following steps:
IMPORTANT:
Make sure that a printer has been properly set up before
proceeding with this section
1. To access the print menu, press the [PRNT] key.
NOTE:
The print menu is not protected by the security feature and
a password is never required to access this menu.
2. Press [F3] = PROG.
3. Use the [], [] and [F1]-[F4] keys to select the desired site
file to print.
NOTE:
All site files currently in memory appear on the option bar.
The active site file is always listed as the first choice (Work).
The model GF868 returns to the standard data display
screen and generates a site file printout similar to the one
shown in figure 7. The printout continues until the entire file
has been printed or until a STOP command is issued (see the
instructions for the STOP submenu.)
Mass Flow Units
MUit
CHAN SYSTEM PARAMETERS
Equation
Ch1 Channel LABEL Channel MESSAGE
CHAN ACTIVE PARAMETERS
Site status
Skan/measure mode
Burst
Skan Only
Standard Equation
Thousands ACF
/min
0
Pd
At 9:54:39 AM on 11 FEB 99
Wit
h 1K FIFO and 1113 receiver board
Model GX868G3G
PROGRAM PARAMETERS of SITE NAME
Mass Flow Time
MDOT Decimal Digits
Volumetric Units
Volumetric Time
VOL Decimal Digits
Totalizer Units
TOT Decimal Digits 0
Actual cubic ft
Pounds
/sec
0
Figure 7: Typical site file printout
4.5 Stop printing
Use the STOP submenu to terminate the printing of live,
logged or site data. To stop any active printing activity, see
figure 16 and complete the following steps:
IMPORTANT:
Make sure that a printer has been properly set up before
proceeding with this section.
1. To access the print menu, press the [PRNT] key.
NOTE:
The print menu is not protected by the security feature and
a password is never required to access this menu.
2. Press [F4] = STOP.
3. Press [F1] to continue printing or press [F2] to stop the
currently active printing job.
NOTE:
After the STOP command has been issued, the printer will
complete the printing of any data already in the printer
buffer. Either wait for the printer to finish or turn the printer
off to empty the buffer immediately
The model GF868 returns to the standard data display
screen and normal measurement taking.
56
