T5 Flare Gas Transducer Installation Guide 61
Chapter 4. Specifications
Chapter 4. Specifications
4.1 T5 Transducer Physical Specifications
4.2 T5 Transducer Certifications
Applications: Hazardous Area, Flare Gas, Hydrocarbon Gases, Saturated Steam
Installation Type: Wetted
Material:
Standard:
Titanium
Optional:
316 Stainless Steel, Monel
or Hastelloy
Field Mounting: Flowcell, Hot or Cold Tap
Process Connection: Flanged, 1.5 in. to 3 in. (40 mm to 80 mm)
Holder Type: Insertion Mechanism
Holder Ratings: 150#, 300#, 600#
Operating Frequency:
Standard:
100 kHz
Optional:
50 kHz and 200 kHz
Pressure Range: 0 to 2700 psig
Electrical Rating: 200 V peak-to-peak, 5 mA
Ambient Temperature Range: –40° to +140°F (–40° to +60°C)
Process Temperature Range: –364° to +500°F (–220° to +260°C)
North American -
Explosion proof:
Class I, Division 1, Group C, D
Class II, Class III, Division 1, Group E, F, G
European/International -
Flameproof:
II 2 G Ex d IIC T6...T2 Gb (T code dependent on Process Temperature)
Tamb –40° to +140
o
F (–40° to +60
o
C)
KEMA 01ATEX2045X: IECEx KEM09.0009X
Standards used: EN 60079-0:2012, EN 60079-1:2007, IEC 60079-0:2011,
IEC 60079-1:2007, Ed. 6.
North American -
Weatherproof:
IP66, TYPE 4X
200Vpp, 5mA
European/International -
Weatherproof:
IP 66
