T5 Flare Gas Transducer Installation Guide 25

Chapter 1. Installing Pipe Nozzles

1.3.6 Installing the Second Welding Boss and Nozzle

Using the same procedures used for installing the first welding boss and nozzle, install the second welding boss and

nozzle at the marked position on the pipe

The completed installation should appear as shown below.

45°

FLOW

WELDING BOSS

NOZZLE

2 PLACES
