Panasonic AW-HE40HWP

90
Displaying the web screen using a mobile terminal
Connect the mobile terminal to the unit, and display the
unit’s images. Refreshing to the latest images takes place
automatically.
Operations such as panning, tilting and zooming can also be
performed from the mobile terminal.
The following models are supported as mobile terminals (as
of August 2014).
● For the most recent information on compatible operating
systems and web browsers, visit the support desk at the
following web site.
http://pro-av.panasonic.net/
Mobile terminal Specifications
iPad
iPhone
iPod touch
iOS 7.1
Android™ terminals Android 4.3
● Use a standard browser with an Android terminal.
● Input the user name and password if the authorization
dialog box is displayed.
The initial settings for the user name and password are
given below.
User name admin
Password 12345
In order to ensure security, the password for the user
name of “admin” must be changed without fail.
(see page 78)
● If the mobile terminal does not support the character code
UTF-8, the characters cannot be displayed properly.
1 Input “http://IP address/mobile/ ” using the
mobile terminal, and press the enter button.
The unit’s images will now be displayed.
● Pan/Tilt
When this button is pressed, the buttons for performing
the pan/tilt operations are displayed on the screen.
The camera is panned toward the left.
The camera is tilted upward.
The camera is tilted downward.
The camera is panned toward the right.
● The camera will not move diagonally even when the
pan button and tilt buttons are pressed at the same
time.
(The button pressed first takes precedence.)
Note
● Zoom
The unit’s zooming operations are performed using these
buttons.
Use this to adjust the zoom (magnification) to
1.0x.
Use this to adjust the zoom (magnification) in
the Wide direction.
Use this to adjust the zoom (magnification) in
the Tele direction.
