Installation Instructions
System example 5 (NDI|HX compatible switcher)
Accessory AC adaptor
AW-UE80
AW-UE80
*
LAN cable
Switching hub
NDI|HX compatible switcher
AV-HLC100
Monitor Monitor
External DC
power supply
Remote Camera Controller
AW-RP150
*
: The AC adaptor provided with the unit is not shown in the above figure.
