Panasonic BL-C230A

7
BL-C230A
Wireless Specifications
*1) See 2.1. for details.
*2) Frame rate may decrease in the following situations.
-When buffering images
-When using color night view mode
-When many users are viewing camera images
*3) The camera supports POP Before SMTP Authentication and SMTP Authentication. PLAIN, LOGIN, and CRAM-MD5 SMTP
Authentication are supported. SSL supports SMTP over SSL. STARTTLS is not supported.
*4) When the temperature is 20 °C (68 °F)
2.1. Internal Memory Capacity for Buffered Images
The camera‘s internal memory can buffer images according to the table below.
Note
• All values are approximate.
• H.264 images cannot be buffered to the camera’s internal memory.
JPEG images (videos and still images)
Note
• The maximum number of images that can be buffered depends on image resolution and image quality.
MPEG-4 videos
For information about MPEG-4 image capacity, see the Panasonic Network Camera support site at
http://panasonic.net/pcc/support/netwkcam/.
Note
• The maximum amount of video that can be buffered depends on image resolution, network bandwidth, and the frame rate and bit
rate set for the streaming method.
2.2. Compatible Panasonic VIERA TVs
The camera is compatible with the following Panasonic VIERA TVs (as of October, 2009).
G10 series, G15 series, V10 series, Z1 series
Items Specifications
Communication Standard IEEE 802.11b, 802.11b/g, 802.11g exclusive
Data Transfer Mode IEEE 802.11b: Direct Sequence Spectrum Spread (DS-SS)
IEEE 802.11g: Orthogonal Frequency Division Multiplexing (OFDM)
Frequency Range 2.412-2.462 GHz
Channel 1-11
Security SSID, WEP (64/128/152 bit), WPA-PSK (TKIP), WPA2-PSK (AES)
Resolution Specification Snapshot Image Quality
Favor Clarity Standard Favor Motion
640 x 480 File Size 50 KB 50 KB 35 KB 27 KB
No. of Images (Saved to PC) 360 520 680
320 x 240 File Size 25 KB 25 KB 16 KB 10 KB
No. of Images (Saved to PC) 730 1160 1880
192 x 144 File Size 10 KB 10 KB 7 KB 5 KB
No. of Images (Saved to PC) 1880 2710 3850
