Panasonic BL-C230A - Page 75

75
BL-C230A
16.3.6. LENS Board Parts
16.3.7. RF Board Parts
T
BLC230A
R940 ERJ2GEJ102 1k
R947 ERJ2GEJ103 10k
(VARISTOR)
CF901 D4ZZ00000024 VARISTOR
(SWITCH)
SW903 K0H1BB000063 PUSH SWITCH
(TRANSFORMER)
T901 G5BYC0000030 TRANSFORMER
(CRYSTAL OSCILLATOR)
X901 H0A327200165 CRYSTAL OSCILLATOR
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB4 PNWP4C230A LENS BOARD ASS’Y (RTL)
(IC)
IC401 C4ZZ00000056 IC
(CAPACITORS)
C401 F1H0G4750001 4.7
C404 ECUE1C104ZFQ 0.1
C406 ECUE1H101JCQ 100p
C407 ECUE1C104ZFQ 0.1
C408 F1H0G4750001 4.7
C410 ECUE1H101JCQ 100p
C412 ECUE1C104ZFQ 0.1
(CONNECTORS)
CN401 K1MN27AA0058 CONNECTOR
CN402 K1MN27AA0058 CONNECTOR
(COIL AND CERAMIC FIL-
TERS)
FL401 J0HAYY000047 IC FILTER
FL402 J0HAYY000047 IC FILTER
L411 J0JYC0000055 COIL
(RESISTORS)
R402 ERJ2GE0R00 0
R403 ERJ2GE0R00 0
R404 ERJ2GE0R00 0
(COMPONENTS PART)
RA401 D1H84704A024 RESSISTOR ARRAY
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB5 PNWP5C230A RF BOARD ASS’Y (RTL)
Safety Ref.
No.
Part No. Part Name & Description Remarks
