11
Model
Indoor CS-VU9SKQ
Outdoor CU-VU9SKQ
Refrigeration
Cycle
Control Device Capillary Tube
Refrigerant Oil cm
3
FW50S (320)
Refrigerant Type g (oz) R32, 710 (25.1)
Dimension
Height (I/D / O/D) mm (inch) 280 (11-1/32) / 542 (21-11/32)
Width (I/D / O/D) mm (inch) 950 (37-13/32) / 780 (30-23/32)
Depth (I/D / O/D) mm (inch) 318 (12-17/32) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 13 (29) / 29 (64)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height different m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 10 (0.1)
Length for Additional Gas m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16.2
Length mm 550
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coated)
Fin Type Slit Fin
Row × Stage × FPI 2 × 15 × 21
Size (W × H × L) mm 675 × 315 × 25.4
Outdoor
Heat
Exchanger
Fin Material Aluminium (Blue Coated)
Fin Type Slit Fin
Row × Stage × FPI 2 × 24 × 17
Size (W × H × L) mm 25.4 × 504 × 693.4:713.4
Air Filter
Material Polypropelene
Type One-touch
Power Supply Outdoor
Power Supply Cord A -
Thermostat -
Protection Device -
Dry Bulb Wet Bulb
Indoor Operation Range
Maximum °C 32 23
Minimum °C 16 11
Outdoor Operation Range
Maximum °C 43 26
Minimum °C 16 11
1. Cooling capacities are based on indoor temperature of 27°C DRY BULB (80.6°F DRY BULB), 19.0°C WET BULB (66°F WET BULB) and
outdoor air temperature of 35°C DRY BULB (95°F DRY BULB), 24°C WET BULB (75.2°F WET BULB).
To Next Page
