Panasonic CS-VU18SKQ Service Manual

12
Model
Indoor CS-VU12SKQ
Outdoor CU-VU12SKQ
Performance Test Condition JIS
Power Supply
Phase, Hz Single, 60
V 220 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 1.02 3.40 4.20 1.02 3.40 4.20
BTU/h 3480 11600 14300 3480 11600 14300
kJ/h 3670 12240 15120 3670 12240 15120
Running Current A - 4.0 - - 3.8 -
Input Power W 285 830 1.15k 285 830 1.15k
EER
W/W 3.58 4.10 3.65 3.58 4.10 3.65
BTU/hW 12.21 13.98 12.43 12.21 13.98 12.43
kJ/hW 12.88 14.75 13.15 12.88 14.75 13.15
Power Factor % - 94 - - 95 -
Indoor Noise (H / L / QLo) dB-A 41 / 27 / 19 41 / 27 / 19
Outdoor Noise (H / L / QLo) dB-A 48 / - / - 48 / - / -
Max Current (A) / Max Input Power (W) 6.5 / 1.42k
Starting Current (A) 4.0
Compressor
Type Hermetic Motor (Rotary)
Motor Type Brushless (6 poles)
Output Power W 650
Indoor Fan
Type Cross-Flow Fan
Material ASG20K1
Motor Type DC / Transistor (8 poles)
Input Power W 47.3 - 47.3
Output Power W 30
Speed
QLo rpm 640
Lo rpm 830
Me rpm 1110
Hi rpm 1390
SHi rpm 1510
Outdoor Fan
Type Propeller
Material PP
Motor Type AC / Induction (6 poles)
Input Power W -
Output Power W 27
Speed Hi rpm 950 970
Moisture Removal L/h (Pt/h) 2.0 (4.2)
Indoor
Airflow
QLo m
3
/min (ft
3
/m) 6.00 (212)
Lo m
3
/min (ft
3
/m) 7.70 (272)
Me m
3
/min (ft
3
/m) 10.20 (360)
Hi m
3
/min (ft
3
/m) 12.00 (425)
SHi m
3
/min (ft
3
/m) 12.40 (498)
Outdoor
Airflow
Hi m
3
/min (ft
3
/m) 29.00 (1020) 29.30 (1030)
