Panasonic CS-VU18SKQ Service Manual

113
17.1.4 To Remove Dust Sensor
Screw Tab
Dust Sensor cover
Dust Sensor case
Pull
Electronic
Controller
1. Pull to unhook and remove the dust sensor cover.
2. Remove the particular piece (Dust Sensor case) by remove the screw.
3. Detach the connector.
4. Remove the electronic controller (Dust Sensor) by releasing the tab and pull the electronic controller out.
17.1.5 To Remove nanoe-G Generator
Or
nanoe-G Generator
Push
Push
Electronic Controlle
r
1. Push upward or downward the nanoe-G generator.
2. Detach 2 connectors from electronic controller (nanoe-G).
3. Remove the electronic controller (nanoe-G) by detach the connector. Release the tab and pull the electronic
controller out.
4. Remove nanoe-G generator by pulling it out.
