Panasonic CS-VU18SKQ Service Manual

131
SAFETY REF. NO. PART NAME & DESCRIPTION QTY CS-VU9SKQ CS-VU12SKQ CS-VU18SKQ REMARK
1 CHASSIS 1 ACXD50-00070 ← ←
2 AIR GUIDER C.F. ASSY 1 ACXD30K00010 ← ←
3 EVAPORATOR COMPLETE 1 ACXB30C00650 ACXB30C00660 ACXB30C00890
4 FLARE NUT (LIQUID) 1 CWT251048 ← ←
5 FLARE NUT (GAS) 1 CWT251049 CWT251073 ←
6 BACK COVER CHASSIS 1 ACXD93-00550 ← ←
7 FAN MOTOR 1 L6CBYYYL0166 ← L6CBYYYL0169 O
8 CROSS FLOW FAN COMPLETE 1 ACXH02C00090 ← ←
9 SCREW - CROSS FLOW FAN 1 CWH551146 ← ←
10 BEARING ASS'Y 1 CWH64K1006 ← ← O
11 CONTROL BOARD CASING 1 ACXH10-00160 ← ←
12 PARTICULAR PIECE - TERMINAL 1 ACXD93-00600 ← ←
13 TERMINAL BOARD - COMPLETE 1 CWA28C2616 ← ← O
14 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C04020 ACXA73C04030 ACXA73C04040 O
15
ELECTRONIC CONTROLLER
(CONNECTOR)
1 ACXA73-02180 ← ← O
16 LEAD WIRE - COMPLETE (CN-STM601) 1 ACXA60C01920 ← ←
17 ELECTRONIC CONTROLLER - HVU 1 N0GE1F000007 ← ← O
18 LEAD WIRE - COMPLETE (CN-CLN) 1 ACXA60C01190 ← ←
19
CASING FOR ELEC. CONTROLLER
(RECEIVER & SWITCH)
1 ACXD93-00590 ← ←
20
ELECTRONIC CONTROLLER
(RECEIVER)
1 ACXA73-00380 ← ← O
21 LEAD WIRE - COMPLETE (CN-RCV) 1 ACXA60C01280 ← ←
22 ELECTRONIC CONTROLLER (SWITCH) 1 ACXA73-00760 ← ← O
23 LEAD WIRE - COMPLETE (CN-SW) 1 ACXA60C01290 ← ←
24
ELECTRONIC CONTROLLER
(INDICATOR)
1 ACXA73-00370 ← ← O
25 LEAD WIRE - COMPLETE (CN-DISP) 1 ACXA60C01270 ← ←
26 SUCTION TEMPERATURE SENSOR 1 ACXA50C00280 ← ← O
27 PIPING TEMPERATURE SENSOR 1 ACXA50C00290 ← ← O
28
CONTROL BOARD COVER
(SIDE CASING)
1 ACXH13-00150 ← ←
29
CONTROL BOARD COVER
(BACK CASING)
1 ACXH13-00160 ← ←
30 DRAIN PAN - COMPLETE 1 ACXH40C00010 ← ←
31
STEPPING MOTOR
(FOR INDICATOR FLAP)
1 ACXA98-00160 ← ← O
32 INDICATOR FLAP 1 ACXE24C00180 ← ←
33 INDICATOR FRONT COVER 1 ACXD93K00020 ← ←
34 DISCHARGE GRILLE - COMPLETE 1 ACXE20C00110 ← ←
35
PARTICULAR PIECE
(FOR VERTICAL VANE)
2 ACXD93-00560 ← ←
36 VERTICAL VANE 10 ACXE24-00190 ← ←
37 CONNECTING BAR 1 ACXE26-00040 ← ←
38
AIR SWING MOTOR ASSY
(VERTICAL VANE)
1 ACXA98K00010 ← ← O
39 GENERATOR COMPLETE 1 ACXH94C00020 ← ← O
40
GEAR - COMPLETE
(FOR HORIZONTAL VANE)
2 ACXH68C00010 ← ← O
41 FULCRUM - COMPLETE 1 ACXH62C00010 ← ←
42 SHAFT 1 ACXH63-00020 ← ←
43
CONTROL BOARD COVER -
(FRONT CASING)
1 ACXH13C00040 ← ←
44 CASING FOR DUST SENSOR 1 ACXD93-00620 ← ←
45 DUST SENSOR 1 ACXA50-00140 ← ← O
46 DUST SENSOR FRONT COVER 1 ACXD93-00630 ← ←
