132
SAFETY REF. NO. PART NAME & DESCRIPTION QTY CS-VU9SKQ CS-VU12SKQ CS-VU18SKQ REMARK
47 FRONT GRILLE-COMPLETE 1 ACXE10C00540 ← ←
48 GRILLE DOOR - COMPLETE 1 ACXE14C00020 ← ←
49 SCREW - FRONT GRILLE COMPLETE 7 XTT4+12CFJ ← ←
50 HORIZONTAL VANE - COMPLETE 1 ACXE24C00210 ← ←
51 FRONT PANEL - COMPLETE 1 ACXE13C00010 ← ← O
52 SCREW - FRONT PANEL 2 XTT4+16CFJ ← ←
53 AIR FILTER (BIG) 2 ACXD00-00110 ← ← O
54 AIR FILTER (SMALL) 2 ACXD00-00120 ← ← O
55
REMOTE CONTROL SWITCH -
COMPLETE
1 ACXA75C00940 ← ←
56 INTAKE GRILLE 1 ACXE22-00150 ← ←
57 OPERATING INSTRUCTION 1 ACXF55-00410 ← ←
58 INSTALLATION INSTRUCTION 1 ACXF60-01740 ← ←
59 INSTALLATION INSTRUCTION 1 ACXF60-02650 ← ←
60 DRAIN HOSE 1 CWH851174 ← ←
61
BAG COMPLETE - INSTALATION
SCREW
1 CWH82C1705 ← ←
62 INSTALLING HOLDER 1 ACXH36-00030 ← ←
(Note)
All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).
“O” marked parts are recommended to be kept in stock.
To Next Page
