Panasonic CU-4E24RBU - Page 102

102
17.1.2.2 Heating
Heating: 60Hz, 230V
Maximum capacity and Input power
Combination
(Capacity)
Indoor Air
Temp.
°F (°C)
DB
Outdoor Air Temp. °F (°C) WB
59.0 (15) 50.0 (10) 42.8 (6) 32.0 (0) 23.0 (-5) 14.0 (-10) 5.0 (-15)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
1.6 + 3.2
60.8 (16) 49045.39 1.65 34336.77 2.03 27242.61 2.26 22611.82 2.45 20748.39 2.56 20032.93 2.54 18041.89 2.43
64.4 (18) 48683.59 1.71 33494.11 2.06 26075.10 2.27 21178.66 2.47 19305.47 2.59 18931.04 2.60 17681.74 2.53
68.0 (20) 48321.79 1.78 32651.45 2.09 24907.60 2.29 19745.50 2.48 17862.56 2.62 17829.15 2.66 17321.60 2.63
69.8 (21) 47787.91 1.82 31933.73 2.11 24433.28 2.31 19829.76 2.49 18622.77 2.62 18830.88 2.66 17975.46 2.64
71.6 (22) 47254.03 1.86 31216.00 2.14 23958.95 2.32 19914.01 2.50 19382.99 2.63 19832.60 2.66 18629.33 2.64
75.2 (24) 46186.26 1.93 29780.56 2.19 23010.30 2.36 20082.51 2.52 20903.43 2.63 21836.06 2.67 19937.05 2.65
1.6 + 5.0
60.8 (16) 53748.37 1.70 37629.33 2.08 29854.91 2.31 24780.08 2.52 22737.96 2.63 21953.90 2.61 19771.93 2.49
64.4 (18) 53351.88 1.76 36705.87 2.11 28575.46 2.33 23209.49 2.53 21156.68 2.66 20746.34 2.67 19377.25 2.60
68.0 (20) 52955.39 1.82 35782.41 2.14 27296.00 2.35 21638.91 2.55 19575.40 2.69 19538.79 2.73 18982.58 2.70
69.8 (21) 52370.31 1.86 34995.87 2.17 26776.19 2.37 21731.24 2.55 20408.52 2.69 20636.58 2.73 19699.14 2.71
71.6 (22) 51785.24 1.90 34209.32 2.20 26256.38 2.38 21823.57 2.56 21241.63 2.69 21734.36 2.73 20415.70 2.71
75.2 (24) 50615.08 1.98 32636.23 2.25 25216.77 2.42 22008.23 2.58 22907.87 2.70 23929.93 2.74 21848.82 2.72
2.0 + 2.5
60.8 (16) 47029.83 1.59 32925.67 1.96 26123.05 2.18 21682.57 2.37 19895.72 2.47 19209.66 2.45 17300.44 2.34
64.4 (18) 46682.89 1.65 32117.64 1.99 25003.53 2.19 20308.31 2.38 18512.10 2.50 18153.05 2.51 16955.10 2.44
68.0 (20) 46335.96 1.71 31309.61 2.02 23884.00 2.21 18934.04 2.39 17128.48 2.53 17096.44 2.57 16609.76 2.54
69.8 (21) 45824.02 1.75 30621.38 2.04 23429.17 2.23 19014.83 2.40 17857.45 2.53 18057.00 2.57 17236.75 2.54
71.6 (22) 45312.08 1.79 29933.16 2.07 22974.34 2.24 19095.62 2.41 18586.43 2.53 19017.57 2.57 17863.74 2.55
75.2 (24) 44288.20 1.87 28556.70 2.12 22064.67 2.28 19257.20 2.43 20044.38 2.54 20938.69 2.57 19117.72 2.56
2.0 + 3.2
60.8 (16) 49045.39 1.64 34336.77 2.02 27242.61 2.25 22611.82 2.44 20748.39 2.55 20032.93 2.53 18041.89 2.42
64.4 (18) 48683.59 1.71 33494.11 2.05 26075.10 2.26 21178.66 2.46 19305.47 2.58 18931.04 2.59 17681.74 2.52
68.0 (20) 48321.79 1.77 32651.45 2.08 24907.60 2.28 19745.50 2.47 17862.56 2.61 17829.15 2.65 17321.60 2.62
69.8 (21) 47787.91 1.81 31933.73 2.11 24433.28 2.30 19829.76 2.48 18622.77 2.61 18830.88 2.65 17975.46 2.62
71.6 (22) 47254.03 1.85 31216.00 2.13 23958.95 2.31 19914.01 2.49 19382.99 2.61 19832.60 2.65 18629.33 2.63
75.2 (24) 46186.26 1.93 29780.56 2.18 23010.30 2.35 20082.51 2.50 20903.43 2.62 21836.06 2.66 19937.05 2.64
2.0 + 5.0
60.8 (16) 53748.37 1.69 37629.33 2.07 29854.91 2.30 24780.08 2.51 22737.96 2.62 21953.90 2.60 19771.93 2.48
64.4 (18) 53351.88 1.75 36705.87 2.10 28575.46 2.32 23209.49 2.52 21156.68 2.65 20746.34 2.66 19377.25 2.58
68.0 (20) 52955.39 1.82 35782.41 2.13 27296.00 2.34 21638.91 2.53 19575.40 2.68 19538.79 2.72 18982.58 2.69
69.8 (21) 52370.31 1.86 34995.87 2.16 26776.19 2.36 21731.24 2.54 20408.52 2.68 20636.58 2.72 19699.14 2.69
71.6 (22) 51785.24 1.90 34209.32 2.19 26256.38 2.37 21823.57 2.55 21241.63 2.68 21734.36 2.72 20415.70 2.70
75.2 (24) 50615.08 1.98 32636.23 2.24 25216.77 2.41 22008.23 2.57 22907.87 2.69 23929.93 2.73 21848.82 2.71
