17.2 CU-4E24RBU
17.2.1 Operation Characteristics
17.2.1.1 One Indoor Unit Operation
 Cooling Characteristic
[Condition] Room temperature: 80.0°F (26.7°C) (DBT), 67.0°F (19.4°C) (WBT)
Operation condition: High fan speed
Piping Length: 7.5m (24.6 ft)
230V 60Hz
A) Indoor unit capacity: Cooling (2.0: CS-ME7RKUA), service mode frequency = 20Hz
Gas Side Piping
Pressure (PSI (MPa))
Current
(A)
Outlet Air
(°F (°C))
Outdoor Air Temperature (°F (°C))
10
(-12.2)
20
(-6.6)
30
(-1.1)
40
(4.4)
50
(10.0)
60
(15.5)
70
(21.1)
80
(26.6)
90
(32.2)
100
(37.7)
110
(43.3)
120
(48.8)
ME7RKUA
59.0 (15.0)
60.0 (15.5)
61.0 (16.1)
62.0 (16.6)
63.0 (17.2)
64.0 (17.7)
2.000
2.500
3.000
3.500
4.000
4.500
5.000
130.000 (0.896)
135.000 (0.930)
140.000 (0.965)
145.000 (0.999)
150.000 (1.034)
155.000 (1.068)
160.000 (1.103)
