2.2 CU-4E24RBU
Item Unit OUTDOOR UNIT
Indoor Unit Combination 1.6kW + 1.6kW + 2.0kW + 2.0kW
Power Source 1 Phase, 208-230V, 60Hz (Power supply from outdoor unit)
Cooling Operation
Capacity
kW 7.02 (3.0 ~ 9.2)
BTU/h 24000 (10200 ~ 31400)
Electrical
Data
Running Current A 9.9 - 8.9
Power Input kW 1.91 (0.53 ~ 2.87)
EER
W/W 3.66 (5.66 ~ 3.21)
BTU/hW 12.55 (19.25 ~ 10.95)
Noise
Sound Pressure Level dB-A (H/L) 55 / -
Sound Power Level dB (H/L) 71 / -
Heating Operation
Capacity
kW 11.1 (4.2 ~ 14.2)
BTU/h 37800 (14300 ~ 48500)
Electrical
Data
Running Current A 15.3 - 13.9
Power Input kW 3.03 (0.70 ~ 4.38)
COP
W/W 3.66 (6.00 ~ 3.24)
BTU/hW 12.45 (20.45 ~ 11.05)
Noise
Sound Pressure Level dB-A (H/L) 55 / -
Sound Power Level dB (H/L) 71 / -
Maximum Current A 21.1
Starting Current A 15.3
Circuit Breaker Capacity A 45
Dimension
Height mm (inch) 999 (39-11/32)
Width mm (inch) 940 (37-1/32)
Depth mm (inch) 340 (13-13/32)
Net Weight kg (lb) 83 (183)
Connection Cable 3 + 1 (Earth) min AWG16
Pipe Length Range (1 room) m (ft) 3 ~ 25 (9.8 ~ 82.0)
Maximum Pipe Length (Total Room) m (ft) 70 (229.6)
Refrigerant Pipe Diameter
Liquid Side mm (inch) 6.35 (1/4)
Gas Side mm (inch) 9.52 (3/8), (E24: 12.70 (1/2))
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Rated Output W 1.30k
Air Circulation
Type Propeller Fan
Motor Type DC Motor (8-poles)
Rated Output W 90
Fan Speed High (Cooling / Heating) RPM 600 / 700
Heat Exchanger
Type Plate fin configuration forced draft type
Tube Material Copper
Fin Material Aluminum (Blue Coated)
Row / Stage 2 / 46
FPI 19
Air Volume High (Cooling / Heating)
m
