25
8. Printed Circuit Board
8.1 Main Printed Circuit Board
8.1.1 CU-3E19RBU
CN-EV1
CN-TH1
CN-EV2
CN-DIS
CN-TH3
CN-TH2
CN-TH4
CN-PSW1
CN-FM1
CN-DISP1
CN-NMODE
CN-DISP2
CN-EV3
POWER
T
RANSISTOR
(IPM)
CURRENT
TRANSFORMER
(CT)
