17.2.2 Capacity Table
17.2.2.1 Cooling
Cooling: 60Hz, 230V
Maximum capacity and Input power
Combination
(Capacity)
Outdoor Air
Temp.
°F (°C)
DB
Indoor Air Temp. °F (°C) WB
60.8 (16) 63.5 (17.5) 64.4 (18) 66.2 (19) 71.6 (22) 75.2 (24)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
Total
Capacity
(BTU/h)
Input
Power
(kW)
1.6 + 3.2
71.6 (22) 13784.48 0.64 14102.93 0.64 14209.08 0.64 14421.39 0.64 19921.53 1.03 23588.29 1.29
77.0 (25) 15717.95 1.08 16127.39 1.06 16263.87 1.06 16536.83 1.05 20658.52 1.30 23406.32 1.46
84.2 (29) 17605.92 1.56 18060.85 1.53 18212.50 1.52 18515.79 1.51 21163.50 1.62 22928.64 1.69
89.6 (32) 18424.80 1.83 18925.23 1.81 19092.04 1.80 19425.65 1.79 23693.36 1.81 26538.50 1.83
95.0 (35) 18743.25 2.04 19266.43 2.03 19440.82 2.02 19789.60 2.01 21004.27 1.98 21814.05 1.96
104.0 (40) 18220.08 2.24 18743.25 2.25 18917.64 2.25 19266.43 2.26 18638.62 2.20 18220.08 2.16
109.4 (43) 17219.23 2.24 17742.40 2.29 17916.79 2.30 18265.57 2.33 19016.21 2.29 19516.64 2.26
114.8 (46) 15695.20 2.19 16218.37 2.27 16392.76 2.30 16741.55 2.35 17751.50 2.34 18424.80 2.33
1.6 + 5.0
71.6 (22) 17111.77 0.83 17507.09 0.83 17638.86 0.83 17902.41 0.83 24730.18 1.33 29282.02 1.67
77.0 (25) 19511.93 1.40 20020.20 1.38 20189.63 1.37 20528.47 1.36 25645.06 1.68 29056.12 1.90
84.2 (29) 21855.62 2.02 22420.37 1.99 22608.62 1.98 22985.11 1.96 26271.93 2.10 28463.14 2.19
89.6 (32) 22872.17 2.38 23493.38 2.35 23700.46 2.34 24114.60 2.32 29412.45 2.36 32944.34 2.38
95.0 (35) 23267.49 2.65 23916.94 2.63 24133.43 2.62 24566.40 2.61 26074.27 2.57 27079.51 2.55
104.0 (40) 22618.03 2.91 23267.49 2.92 23483.97 2.92 23916.94 2.93 23137.60 2.85 22618.03 2.80
109.4 (43) 21375.59 2.91 22025.05 2.97 22241.53 2.99 22674.50 3.03 23606.33 2.97 24227.55 2.93
114.8 (46) 19483.70 2.85 20133.15 2.95 20349.64 2.98 20782.61 3.05 22036.34 3.04 22872.17 3.03
1.6 + 70
71.6 (22) 20201.39 1.15 20668.09 1.15 20823.66 1.15 21134.79 1.15 29195.35 1.85 34569.05 2.31
77.0 (25) 23034.92 1.94 23634.96 1.91 23834.98 1.90 24235.00 1.88 30275.42 2.33 34302.37 2.63
84.2 (29) 25801.78 2.79 26468.49 2.75 26690.73 2.74 27135.20 2.71 31015.47 2.90 33602.32 3.03
89.6 (32) 27001.86 3.29 27735.25 3.25 27979.71 3.24 28468.63 3.21 34723.03 3.26 38892.63 3.29
95.0 (35) 27468.56 3.67 28235.28 3.64 28490.85 3.63 29002.00 3.61 30782.12 3.56 31968.87 3.53
104.0 (40) 26701.84 4.02 27468.56 4.04 27724.13 4.04 28235.28 4.05 27315.22 3.94 26701.84 3.87
109.4 (43) 25235.07 4.02 26001.79 4.11 26257.37 4.14 26768.51 4.19 27868.59 4.11 28601.97 4.05
114.8 (46) 23001.59 3.94 23768.31 4.08 24023.88 4.13 24535.03 4.22 26015.13 4.20 27001.86 4.19
2.0 + 2.5
71.6 (22) 13784.48 0.66 14102.93 0.66 14209.08 0.66 14421.39 0.66 19921.53 1.06 23588.29 1.32
77.0 (25) 15717.95 1.11 16127.39 1.09 16263.87 1.09 16536.83 1.08 20658.52 1.34 23406.32 1.51
84.2 (29) 17605.92 1.60 18060.85 1.58 18212.50 1.57 18515.79 1.55 21163.50 1.66 22928.64 1.74
89.6 (32) 18424.80 1.89 18925.23 1.86 19092.04 1.86 19425.65 1.84 23693.36 1.87 26538.50 1.89
95.0 (35) 18743.25 2.10 19266.43 2.09 19440.82 2.08 19789.60 2.07 21004.27 2.04 21814.05 2.02
104.0 (40) 18220.08 2.31 18743.25 2.32 18917.64 2.32 19266.43 2.32 18638.62 2.26 18220.08 2.22
109.4 (43) 17219.23 2.31 17742.40 2.36 17916.79 2.37 18265.57 2.40 19016.21 2.36 19516.64 2.32
114.8 (46) 15695.20 2.26 16218.37 2.34 16392.76 2.37 16741.55 2.42 17751.50 2.41 18424.80 2.40
