Ref. No. Part No. Part Name &
Description
Pcs Remarks
W778 ERJ3GEY0R00V 1/10W 0 1
X3002 H0D357400067 OSCILLATOR 1
X6001 H0D120500009 OSCILLATOR 1
X7501 H0D100500016 CRYSTAL
OSCILLATOR
1
ZB7501 RMN0870J HOLDER 1
ZB7502 RMN0871J HOLDER 1
ZJ3001 K9ZZ00001279 EARTH PLATE 1
■ VEP04915A FRONT(L)P.C.B. 1 (RTL)
C3801 ECJ1VF1H103Z 50V 0.01U 1
C3802 ECJ1VF1C104Z 16V 0.1U 1
C7701 ECJ1VF1C104Z 16V 0.1U 1
IC7701 PNA4618M13VT IC 1
JK3802 K1CB104A0017 JACK,S VIDEO 1
JK4600 K2HA307A0009 JACK,AV IN 1
LB3301 ERJ3GEY0R00V 1/10W 0 1
LB3302 ERJ3GEY0R00V 1/10W 0 1
LB3303 ERJ3GEY0R00V 1/10W 0 1
LB4301 ERJ3GEY0R00V 1/10W 0 1
LB4302 ERJ3GEY0R00V 1/10W 0 1
PP4601 K1KA12B00136 CONNECTOR(12P) 1
R3801 ERJ3GEYJ750V 1/10W 75 1
R3802 ERJ3GEYJ750V 1/10W 75 1
R3803 ERJ3GEYJ750V 1/10W 75 1
R3804 ERJ3GEYJ102V 1/10W 1K 1
R7701 ERJ3GEYJ123V 1/10W 12K 1
R7702 ERJ3GEYJ153V 1/10W 15K 1
R7703 ERJ3GEYJ221V 1/10W 220 1
S7701 EVQ11G07K SWITCH,POWER 1
S7702 EVQ11G07K SWITCH,EJECT 1
■ VEP07B00A FRONT(R)P.C.B. 1 (RTL)
D27501 B3AAA0000752 DIODE 1
D27503 B3ACA0000273 DIODE 1
D27505 B3ADA0000173 DIODE 1
PP27501 K1KA10B00196 CONNECTOR(10P) 1
QR27501 UNR521100L TRANSISTOR 1
QR27503 UNR521100L TRANSISTOR 1
QR27505 UNR521100L TRANSISTOR 1
R27501 ERJ3GEYJ271V 1/10W 270 1
R27502 ERJ3GEYJ152V 1/10W 1.5K 1
R27503 ERJ3GEYJ391V 1/10W 390 1
R27505 ERJ3GEYJ391V 1/10W 390 1
R27508 ERJ3GEYJ152V 1/10W 1.5K 1
R27509 ERJ3GEYJ152V 1/10W 1.5K 1
R27516 ERJ3GEYJ272V 1/10W 2.7K 1
R27517 ERJ3GEYJ222V 1/10W 2.2K 1
R27532 ERJ3GEYJ222V 1/10W 2.2K 1
S27501 EVQ11G07K SWITCH,OPEN/CLOS
E
1
S27502 EVQ11G07K SWITCH,CH DOWN 1
S27503 EVQ11G07K SWITCH,STOP 1
S27504 EVQ11G07K SWITCH,CH UP 1
S27505 EVQ11G07K SWITCH,PLAY 1
S27506 EVQ11G07K SWITCH,REC 1
S27507 EVQ11G07K SWITCH,D2V 1
S27508 EVQ11G07K SWITCH,V2D 1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
S27509 EVQ11G07K SWITCH,SELECT 1
S27510 EVQ11G07K SWITCH,RESET 1
■ VEP73144A SD/DV JACK
P.C.B.
1 (RTL)
C66802 F1H1A225A051 10V 22U 1
LB66801 J0JHC0000032 COIL 1
LB66802 J0JHC0000045 COIL 1
P66801 K1NA09E00083 CONNECTOR(9P) 1
P66802 K1MY20AA0021 CONNECTOR(20P) 1
P66803 K1FY104B0006 CONNECTOR(4P) 1
R66812 ERJ3GEYJ820V 1/10W 82 1
R66814 ERJ3GEYJ820V 1/10W 82 1
R66815 ERJ3GEYJ330V 1/10W 33 1
RX66802 EXB38V820JV RESISTOR-
RESISTOR
1
■ VEP09147A DIGITAL IF
P.C.B.
1 (RTL)
C1001 F2A1C1210017 16V 120P 1
C1002 F1H1C105A095 16V 1U 1
C1003 F1H1C104A071 16V 0.1U 1
C1004 F1H1C104A071 16V 0.1U 1
C1005 ECJ1VC1H270J 50V 27P 1
C1007 ECJ1VB1H103K 50V 0.01U 1
C1009 F2A0J6810007 6.3V 680P 1
C1101 ECQU2A683MLC 0.068U 1
C1102 F1B2G1010001 100U 1
C1103 F1B2G1010001 100U 1
C1104 ECQU2A223MLC 0.022U 1
C1105 F1B2G4710001 470U 1
C1106 F1B2G4710001 470U 1
C1107 F2B2E2210011 250V 220U 1
C1108 F1B2G1020002 1000P 1
C1110 F2A1V5600013 35V 56U 1
C1111 F1B3A3920001 3900P 1
C1112 ECJ1VC1H331J 50V 330P 1
C1113 ECJ1VB1H102K 50V 1000P 1
C1114 ECJ1VC1H221J 50V 220P 1
C1115 ECJ1VB1H332K 50V 3300P 1
C1130 F2A1V5600013 35V 56U 1
C1131 F1B3A2720001 1KV 2700P 1
C1132 ECJ1VB1H102K 50V 1000P 1
C1133 ECJ1VC1H331J 50V 330P 1
C1134 ECJ1VB1H392K 50V 3900P 1
C1200 F2A1E6810017 25V 680U 1
C1201 F2A1E6810017 25V 680U 1
C1203 F2A1C1210012 16V 120P 1
C1300 F2A1A1220012 10V 1200U 1
C1301 F2A1A6810017 10V 680U 1
C1351 ECJ1VB1C473K 16V 0.047U 1
C1352 F1H1C104A071 16V 0.1U 1
C1371 ECJ1VB1C473K 16V 0.047U 1
C1372 F1H1C104A071 16V 0.1U 1
C1400 F2A0J6800003 6.3V 68P 1
C1401 F1H1C105A095 16V 1U 1
C1402 F1H1C105A095 16V 1U 1
C1403 ECJ1VB1H103K 50V 0.01U 1
C1410 F2A1C5600019 16V 56P 1
C1420 F2A1A1820007 10V 1800U 1
C1421 F2A1A6810017 10V 680U 1
C1430 F2A0J1220028 6.3V 1200P 1
C1431 F2A0J5610005 6.3V 560P 1
C1432 F1H1C105A095 16V 1U 1
C1433 F2A1A1010072 10V 100U 1
C1440 F2A1C5610006 16V 560U 1
C1441 F2A1C1210012 16V 120P 1
C1450 F2A1H2200055 50V 22U 1
119
DMR-EZ47VP / DMR-EZ475VP
