Panasonic DMR-EZ47VP

9.9. Rear Panel, Fan Motor
9.9.1. Only Fan motor
1. Disconnect Fan Connector.
2. Remove 2 Screws (A) to Remove Fan Motor.
9.9.2. Rear panel with fan motor
1. Disconnect Fan Connector.
2. Remove 6 Screws (B) and 2 Screws (C).
3. Unlock 2 Locking Tabs (A) to remove Rear Panel with Fan
Motor.
9.10. Digital P.C.B.
1. Remove 2 Screws (A) and 2 FFCs.
And lift up Digital P.C.B. slightly so to disconnect
connectors to remove Digital P.C.B..
40
DMR-EZ47VP / DMR-EZ475VP
