Ref. No. Part No. Part Name &
Description
Pcs Remarks
ZJ37001 K9ZZ00001279 EARTH PLATE 1
ZJ37002 K9ZZ00001279 EARTH PLATE 1
ZJ37003 K9ZZ00001279 EARTH PLATE 1
ZJ37004 K9ZZ00001279 EARTH PLATE 1
■ CASING/ACCESSORY
/PACKING
1
1 L6FALCCE0020 FAN MOTOR 1
2 RGR0374A-B2 REAR PANEL 1 (EZ47V)
2 RGR0374A-D REAR PANEL 1 (EZ475V)
3 RHD30111-3 SCREW 17
4 RHD30119-L SCREW 12
5 RHD30148 SCREW 1
6 RHDC0023 SCREW 3
7 RKA0137-K FOOT RUBBER 2
8 RKA0178-X FOOT 2
9 RMA2044 DVD ANGLE 1
10 RMA2060 REAR ANGLE 1
11 RMX0298 PCB SPACER 1
12 RMX0354 MECHA SPACER(F) 1
13 RMX0355 MECHA SPACER(R) 1
14 RMX0390 PCB SUPPORT 1
15 RMZ0891 INSULATION SHEET 1
16 RHD26045-J SCREW 3
17 RYP1369B-K FRONT PANEL
ASS’Y 1
1 (EZ47V)
17 RYP1369E-K FRONT PANEL
ASS’Y 1
1 (EZ475V)
17-1 RGK2065-K FL WINDOW 1
17-2 RGU2475-S DUBBING BUTTON 1
17-4 RGU2525A-K1 OPERATION BUTTON 1
17-5 RKF0784A-K TRAY DOOR 1
17-6 RMB0870 TRAY SPRING 1
17-7 RKF0783A-K BLINDER PANEL 1
17-8 VMB2521 BLINDER SPRING 1
18 VEE1D23 WIRE WITH
CONNECTOR
1
19 VHD1092-1 SCREW 1
20 VKC0295 HOLDER 2
21 VWJ1728-RW FFC(6P) 1
22 VWJ1933-2 FFC(40P) 1
23 VWJ1934 FFC(10P) 1
24 VWJ1950 FFC(7P) 1
25 XSN3+4FJ SCREW 2
26 XTV26+6FFJ SCREW 1
27 RMC0689 EARTH SPRING(T) 1
28 RHD30113-1K SCREW 4
29 RMC0708-1 EARTH SPRING 2
30 RKM0572-K TOP COVER 1
31 VEP73144A SD/DV JACK
P.C.B.
1 (RTL)
32 VEP06G37A MAIN P.C.B. 1 (RTL)
33 VEP09147A DIGITAL IF
P.C.B.
1 (RTL)
34 RFKB79142DP DIGITAL P.C.B. 1 (RTL)
35 VEP04915A FRONT(L)P.C.B. 1 (RTL)
36 VEP07B00A FRONT(R)P.C.B. 1 (RTL)
40 RHD26054 SCREW 1
41 RMN0885 SPACER 1
42 RMX0398 FFC SPACER 1
43 VXY1961 DVD DRIVE UNIT 1 (RTL)
101 VEG1697KIT RDD CYLINDER
ASS’Y
1
101-1 VMD5464 FPC HOLDER 1
102 VEM0800T CAPSTAN MOTOR 1
103 L1AG00000011 FE HEAD ASS’Y 1
104 VDB1431 TENSION ARM BOSH 1
105 VDG1686 INTERMEDIATE
GEAR
1
106 VDG1685 MAIN CAM GEAR 1
107 VDG1512 IDLER GEAR 2
108 VDG1514 CHANGE GEAR 1
109 VDR0372A REEL TABLE 2
110 VDV0391 CAPSTAN BELT 1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
111 VEM0797 LOADING MOTOR 1
112 VMB3550A CHANGING GEAR
SPRING
1
113 VMD4987 WORM SHAFT
HOLDER
1
114 VMD5466 OPENER PIECE 1
115 VMD4253 LED PRISM 1
116 VML3934 MAIN LEVER 1
117 VML3933 PINCH CHARGE ARM 1
118 VML3632 IDLER ARM 1
119 VMX3092 P4 CAP 1
120 VXA7105 S SHAFT HOLDER 1
121 VXA7106 T SHAFT HOLDER 1
122 L1AE00000044 AC HEAD ASS’Y 1
122-1 VHD1066-2 SCREW 2
122-2 VHD1185 SCREW 1
124 VXL3107 S LOADING ARM 1
125 VXL3108 T LOADING ARM 1
126 VXL3109-7 PINCH ARM 1
127 VXL3110 P5 ARM 1
128 VXL3111-1 TENSION ARM 1
129 VXL3252 S BRAKE ARM 1
130 VXL3343 T BRAKE ARM 1
130-1 VMB3548 T BRAKE SPRING 1
131 VXL3124 CHANGING LEVER 1
132 VXP2133 CENTER CLUTH 1
133 VXP2168 TORQUE CLUTCH 1
134 VMA0L25 TOP PLATE 1
135 VMD5468 SIDE PLATE(L) 1
136 VMD5469 SIDE PLATE(R) 1
137 VXA8265 CASSETTE HOLDER
ASS’Y
1
138 VXL3160 MAIN SHAFT 1
139 VDG1684 SECTOR GEAR 1
141 VML3706 OPENER LEVER 1
142 VHD1044-1 SCREW 1
143 XYN3+C4FJ SCREW 1
144 XTN26+7JFJ SCREW 3
145 XTV26+5FFJ SCREW 2
146 XTV26+8FFJ SCREW 2
148 VHD1117-1 SCREW 3
149 VMX2208 WASHER 1
150 VMX3114 WASHER 1
151 VMX2699 WASHER 1
152 VMX3196 WASHER 1
A1 EUR7659T80 REMOTE CONTROL
ASS’Y
1
A1-1 UR76EC5903A BATTERY COVER 1
A2 K2CB2CB00018 AC CORD 1
A3 K2KA6BA00004 AV CORD 1
A4 K2KZ2BA00001 RF COAXIAL CABLE 1
A5 RPQF0220-2 ACCESSORY BOX 1 (EZ47V)
A5 RPQF0254 ACCESSORY BOX 1 (EZ475V)
A6 RPFC0031-B POLYETHYLENE BAG 1
A7 RQT8853-P OPERATING
INSTRUCTIONS
1 (IA)
A8 K1HA19DA0007 HDMI CABLE 1 (EZ475V)
PC1 RPG8160 PACKING CASE 1 (EZ47V)
PC1 RPG8313 PACKING CASE 1 (EZ475V)
PC2 RPN1965A-1 CUSHION(A) 1
PC3 RPN1965B-1 CUSHION(B) 1
PC4 RPF0459 POLYETHYLENE BAG 1
PC5 RPN1989-1 CUSHION(C) 1
122
DMR-EZ47VP / DMR-EZ475VP
