13.1.5. Power & Digital I/F P.C.B. Address Information
L1201 D-3 C1104 D-8 C7322 B-8 R1134 D-7 R45013 A-7
IC1001 D-2 P1101 E-8 L1300 D-5 C1105 D-8 C7802 B-8 R1135 D-7 R45014 A-7
IC1110 D-7 P1201 E-3 L1420 E-5 C1106 C-8 C7807 B-8 R1138 D-7 R45015 A-7
IC1130 E-7 P31901 A-7 L1430 E-5 C1107 D-7 C7823 C-7 R1139 D-7
IC1200 D-3 P31902 A-7 L1440 D-5 C1108 C-6 C7824 C-8 R1200 D-3 T1110 D-6
IC1350 C-6 P31903 A-6 L7801 C-8 C1110 C-7 C7826 C-8 R1201 D-3 T1130 E-6
IC1370 E-7 P31904 B-3 L31001 B-5 C1111 D-6 C7827 C-8 R1202 D-3
IC1400 E-2 P31905 B-1 L37101 C-6 C1112 D-7 C7829 C-8 R1350 C-6 TU7801 C-8
IC1430 E-4 P31906 B-1 L37102 C-6 C1113 D-7 C7830 C-8 R1351 C-6
IC7301 B-8 P37001 C-6 LB1001 D-2 C1114 C-7 C7831 C-8 R1353 C-6 VA1101 E-7
IC7801 B-8 P37101 B-6 LB1101 D-7 C1115 C-7 C7835 C-8 R1354 C-5 VA1102 E-7
IC31001 C-3 LB1102 D-7 C1130 D-7 C7836 C-7 R1355 C-5
IC31002 B-3 D1001 D-2 LB1103 C-6 C1131 E-7 C7838 C-8 R1356 C-5 F1101 D-8
IC31004 C-3 D1002 D-2 LB1110 D-7 C1132 D-7 C7839 C-8 R1358 C-6
IC37001 C-3 D1003 C-3 LB1130 E-7 C1133 D-7 C31001 B-3 R1361 C-5
IC45001 B-7 D1101 C-7 LB1400 E-5 C1134 D-7 C31002 C-3 R1362 C-5
D1110 C-6 LB1410 E-5 C1200 D-6 C31004 C-3 R1363 C-5
Q1001 D-2 D1111 C-7 LB1450 D-5 C1201 D-5 C31005 B-3 R1370 E-7
Q1110 C-6 D1112 C-7 LB7801 C-8 C1203 D-3 C31006 C-3 R1371 E-7
Q1130 E-7 D1113 C-6 LB7802 C-8 C1300 D-6 C31007 B-3 R1372 E-7
Q1350 C-6 D1115 D-7 LB7803 C-8 C1301 D-5 C31008 B-3 R1373 E-7
Q7801 B-8 D1130 D-7 LB7804 C-8 C1351 C-5 C31009 B-3 R1374 E-6
Q7802 C-5 D1131 D-7 LB7805 C-8 C1352 C-6 C31010 C-3 R1375 E-7
Q37001 D-3 D1132 D-7 LB7806 C-8 C1371 E-7 C31012 C-3 R1376 E-7
D1133 D-7 LB7807 C-8 C1372 E-7 C31014 C-3 R1378 E-7
QR1350 C-5 D1200 D-6 LB7808 C-8 C1400 E-5 C34001 B-7 R1410 E-2
QR7801 C-5 D1201 D-6 LB7809 C-8 C1401 E-2 C37002 C-3 R7301 A-8
QR31001 B-3 D1300 C-6 LB7810 C-8 C1402 E-2 C37108 B-7 R7302 B-8
QR31002 B-3 D1301 C-6 LB7811 C-8 C1403 E-2 C37111 B-6 R7304 B-8
D1350 C-5 LB7812 C-8 C1410 E-6 C37112 B-6 R7305 B-8
CL1201 E-3 D1351 C-5 LB7813 C-7 C1420 E-6 C37114 B-6 R7306 B-8
CL1202 E-3 D1400 E-6 LB7814 C-7 C1421 E-5 C45002 B-7 R7307 B-7
CL1203 E-3 D1410 E-6 LB7815 C-7 C1430 D-5 C45003 B-7 R7308 B-8
CL37101 B-6 D1412 E-2 LB7816 C-8 C1431 D-5 C45004 B-8 R7801 C-8
CL37102 B-6 D1420 E-6 LB34001 A-6 C1432 E-4 C45005 A-8 R7802 C-5
CL37103 B-6 D1430 D-6 LB37101 B-6 C1433 D-4 C45006 A-7 R7803 C-6
CL37104 B-5 D1432 E-5 LB37103 B-6 C1440 D-6 C45015 A-7 R7804 C-7
CL37105 B-5 D1440 D-6 LB37105 B-6 C1441 D-5 C45016 A-7 R7805 C-7
CL37106 B-5 D1450 D-6 LB37108 C-5 C1450 D-5 R31001 C-3
CL37107 A-6 D7801 C-6 LB37109 B-7 C7301 B-8 R1001 D-2 R31002 C-3
CL37108 A-6 D31001 C-3 LB37110 B-6 C7302 A-8 R1002 D-2 R31003 C-3
CL37109 B-7 D31002 C-3 LB37111 B-6 C7304 A-8 R1003 D-2 R31004 C-3
CL37110 B-7 D31003 B-3 LB37112 B-7 C7305 A-8 R1004 D-2 R31005 C-3
CL37111 B-7 LB37113 B-6 C7306 B-8 R1005 D-2 R31007 B-3
CL37112 B-5 IP1001 D-3 LB37114 B-6 C7308 B-8 R1110 C-7 R31008 B-3
CL37113 B-6 IP1400 E-6 C7310 B-8 R1111 C-7 R31009 B-3
CL37114 B-5 IP1410 E-6 C1001 D-2 C7311 B-8 R1113 D-7 R31011 B-3
CL37115 B-6 IP39001 B-2 C1002 D-2 C7312 B-8 R1114 D-7 R34001 A-6
CL37116 B-6 C1003 D-2 C7313 B-8 R1115 D-7 R37001 C-3
CL37117 C-5 FL7301 B-7 C1004 D-2 C7314 B-8 R1116 C-6 R37002 A-6
CL37118 B-6 C1005 D-2 C7316 B-8 R1117 C-7 R37003 C-3
CL37119 C-5 L1001 D-3 C1007 D-2 C7317 A-8 R1118 C-6 R37004 C-3
CL37120 B-7 L1002 D-2 C1009 D-2 C7318 A-8 R1130 D-7 R37008 A-6
CL37121 B-7 L1101 D-8 C1101 E-8 C7319 B-8 R1131 D-7 R37503 B-3
CL37122 C-8 L1102 D-8 C1102 E-8 C7320 B-8 R1132 D-7 R37504 B-3
TL7301 B-8 L1200 D-5 C1103 D-8 C7321 A-8 R1133 D-7 R45012 B-7
Test Point
Transistor-resistor
Transistor
Diode
Capasitor
Coil
FILTER
IC Protector
Tuner
Varistor
Fuse
Resistor
Power & Digital I/F P.C.B.
Integrated Circuit Connector
Transformer
DMR-EZ47VP / DMR-EZ475VP
89
