5-17
5
Excepting the parts of “
value is “0 = short-circuit”.
”, it is acceptable if a small resistance value appears as a reference value unless the
•
Tester terminals
-
Resistance value (ohm)
U
1 k to 10 k
V
1 k to 10 k
W
1 k to 10 k
U
1 k to 10 k
V
1 k to 10 k
W
1 k to 10 k
HIC-
5 k to 20 k
U
20 k to
V
20 k to
W
20 k to
HIC+
20 k to
-CIH+CIH+
Tester terminals
+
Resistance value (ohm)
-CIH+CIH-
U
20 k to
20 k to
V
20 k to
W
20 k to
P
U
V
W
NU
RE1
RE2
(3-phase outdoor unit HIC PC board)
ACXA73-3104* : (U-200PZH2E8, U-250PZH2E8)
■ Outdoor Unit Control HIC PCB
