Panasonic E3 - N O S I E C T I R R E O I N C U V R E S; Airflow Distance Chart

1-9-1
1
1-9. Airflow Distance Chart
4-Way Cassette (Type U3)
0
1
2
3
0
1
2
3
1.5m/s
1.0m/s
0.5m/s
0.3m/s
Vertical air flow distance (m)
Horizontal air flow distance (m)
5 4 3 21012 3 4 5
(Strong wind : Discharge angle approx.65° () Room temperature approx.20°C)
0
1
2
3
0
1
2
3
1.5m/s
1.0m/s
0.5m/s
0.3m/s
Vertical air flow distance (m)
Horizontal air flow distance (m)
5 432101234 5
(Strong wind : Discharge angle approx.30° () Room temperature approx.27°C)
0
1
2
3
0
1
2
3
20
24
26
22
Vertical air flow distance (m)
Horizontal air flow distance (m)
5 432101234 5
(Strong wind : Discharge angle approx.30° () Room temperature approx.27°C)
0
1
2
3
0
1
2
3
32
27
24
30
Vertical air flow distance (m)
Horizontal air flow distance (m)
543210 1 2 3 4 5
(Strong wind : Discharge angle approx.65° () Room temperature approx.20°C)
S-3650PU3E
Heating : Distribution of wind velocity
Heating : Distribution of temperature
Cooling : Distribution of wind velocity
Cooling : Distribution of temperature
