Panasonic E3 - Page 26

1-2-1-1-2
1
(A) Indoor Units
High Static Pressure Ducted Type S-250PE3E5B
MODEL No.
Source
Controller P.C.B. Ass'y
Fan (Number...diameter)
mm
Fan motor
WModel...Nominal output
Power source
rpmNo. of pole...r.p.m. (High)
Coil resistance
(Ambient temperature 20°C)
Ω
VAC, µFRun capacitor
Electronic expansion valve
Coil
Coil resistance (at 20°C)
Ω
Valve body
Heat exchanger
Coil
mmRows...fin pitch
mFace area
2
S-250PE3E5B
220 - 230 - 240V, single-phase, 50Hz
ACXA73C5151*
SIROCCO (2...ø250)
DMUB8D4AC...750W
DMUB8D5AC...750W
DC280V
8P...1180
–
–
–
–
–
Aluminium plate fin / Copper tube
3...1.8
0.642
