77
4
, and
buttons simultaneously for 4 or more seconds.
The “Maintenance func” screen appears on the
LCD display.
5
Press the
6
or
/
button to see each menu.
Select “13. nanoe X” on the LCD display and press the
button.
The nanoe™ X module status of all indoor units will be
displayed.
Normal : The nanoe™ X module is operating normally.
Unsupported : The indoor unit is not available to the
nanoe™ X function.
*1-1 and 1-2 represent the unit number.
*In the case of “Unsupported”, select “8. Detailed
settings” and check the setting data of the Code no. 9.
*If the setting data is “0000”, the nanoe™ X module is
not recognized. Check the status of the connection.
If the display other than “Normal” or “Unsupported”
appears, check the Step
⑦
next page.
Check that the nanoe™ X module status is “Normal”.
The indoor unit on the display can be scrolled up or
down using buttons.
While operating in FAN mode (more than 5 minutes
have elapsed), press the
1
Switch On the earth leakage circuit breaker.
2
Wait until the remote control display returns to
normal.
3
Operate the unit in FAN mode.
<Procedure of CZ-RTC5B>
nanoe™ X Display
When the appears on the remote controller (CZ-RTC5B), the status of the nanoe™ X can be checked
in the following way.
Sel.
20:30 (THU)
Maintenance func
Page [ ] Confirm
0. ECONAVI info.
1. Outdoor unit error data
2. Service contact
3. RC setting mode
20:30 (THU)
START
[ ]
20:30 (THU)
MODE
FAN SPEED
FLAP
FAN
Maintenance func
Sel. Page [ ] Confirm
20:30 (THU)
0. ECONAVI info.
1. Outdoor unit error data
2. Service contact
3. RC setting mode
Maintenance func
Sel. Page [ ] Confirm
20:30 (THU)
Set touch key
12.
11.
Set elec. consumption10.
Check touch key
13. nanoe X
nanoe X
Unit no. Status
Not connected
Unsupported
Normal
1
1
1
2
1
3
-
-
-
Scroll
20:30 (THU)
Fig. 7-14
7-24
