1-3. Other Component Specifications
Outdoor Units U-200PZH2E8
MODEL No.
Outdoor Unit
Power Transformer
Rated
VAC, HzSource
Secondary
Coil resistance
Ω
Thermistor (Coil / Air sensor): TH1, TH2, TH3, TH4
Resistance
kΩ
-20°C： 38.48±2% 20°C： 6.517±2%
-10°C： 23.67±2% 30°C： 4.448±2%
0°C： 15.00±2% 40°C： 3.100±2%
5°C： 12.06±2% 45°C： 2.607±2%
10°C： 9.765±2% 50°C： 2.203±2%
Thermistor (Discharge gas sensor): TH5
Resistance
kΩ
60°C： 13.85±2% 85°C： 5.946±2%
65°C： 11.59±2% 90°C： 5.086±2%
70°C： 9.743±2% 95°C： 4.367±2%
75°C： 8.228±2% 100°C： 3.764±2%
80°C： 6.981±2%  105°C： 3.256±2%
Relay (Comp. Magnetic Contactor)
VACCoil rated
VAC, AContact rating
Coil resistance (at 20°C)
Ω
Sol-Control-Valve
4 way valve
4 way valve
Electro magnetic coil
Thermal cut off temperature
Sol-control-valve
Magnetic coil
U-200PZH2E8
–
–
–
–
–
–
–
–
–
UKV32D322
SHF-20B-46-DC
SQ-D23015-002283 DC15.4V(898mA)
UKV-A392
Outdoor Units U-250PZH2E8
MODEL No.
Outdoor Unit
Power Transformer
Rated
VAC, HzSource
Secondary
Coil resistance
Ω
Thermistor (Coil / Air sensor): TH1, TH2, TH3, TH4
Resistance
kΩ
-20°C： 38.48±2% 20°C： 6.517±2%
-10°C： 23.67±2% 30°C： 4.448±2%
0°C： 15.00±2% 40°C： 3.100±2%
5°C： 12.06±2% 45°C： 2.607±2%
10°C： 9.765±2% 50°C： 2.203±2%
Thermistor (Discharge gas sensor): TH5
Resistance
kΩ
60°C： 13.85±2% 85°C： 5.946±2%
65°C： 11.59±2% 90°C： 5.086±2%
70°C： 9.743±2%  95°C： 4.367±2%
75°C： 8.228±2% 100°C： 3.764±2%
80°C： 6.981±2%   105°C： 3.256±2%
Relay (Comp. Magnetic Contactor)
VACCoil rated
VAC, AContact rating
Coil resistance (at 20°C)
Ω
Sol-Control-Valve
4 way valve
4 way valve
Electro magnetic coil
Thermal cut off temperature
Sol-control-valve
Magnetic coil
U-250PZH2E8
–
–
–
–
–
–
–
–
–
UKV32D322
SHF-35B-67-03
SQ-A2522G-005129 AC220-240V 50-60Hz
UKV-A392
