1 COMPONENTS IDENTIFICATION 3
2 MASSAGE RANGE (MOVEMENT RANGE OF MASSAGE
WHEELS) SHIATSU MASSAGE, SWEDISH MASSAGE,
KNEADING, VIBRATING, TAPPING A, TAPPING B, TAPPING
C, WHOLE BACK ROLLING, REGIONAL ROLLING 5
3 TURNING ON THE POWER
6
4 REQUIRED TOOLS
7
5 ACTUAL WIRING DIAGRAM
8
6 DISPLAY METHOD OF MASSAGE BLOCK TOTAL USE TIME
AND OPERATION TIME
9
7 MOTION OF THE CLUTCH AND BELT BASED ON VARIOUS
MASSAGER OPERATIONS
10
8 CONTROL OF THE AIR-MASSAGE OPERATION
12
9 MASSAGER UP/DOWN SENSOR GEAR ADJUSTMENT
METHOD
13
10 DISASSEMBLY AND ASSEMBLY INSTRUCTION
14
11 ACTUAL WIRING DIAGRAM
50
12 CHECKING
52
13 GREASE
59
14 EXPLODED VIEW
61
15 REPLACEMENT PARTS LIST
68
CONTENTS
Page Page
2
EP3203-U1
