Example 2) When specifying TS for [S1] and [S2], and LD for [D]
(transferring only lower one word)
S1: TS5, S2: TS7, D: LD20
Precautions during programming
In the case of a direct address and index modification address, specify the same type of
device for [S1] and [S2]. Besides, specify [S2] to be equal to or larger than [S1].
Flag operation
Latest error
(SR7)
Hold error
(SR8)
To be set in case of out-of-range values in indirect access (index modification, pointer access).
To be set when S1 is larger than S2.
To be set when the destination range is out of the accessible range.
