Panasonic FPS Series

I/O Allocation
FPΣ User's Manual
60
5.2 FPΣ CPU
The I/O allocation of the FPΣ CPU is fixed.
CPU type Number of I/O points I/O addresses
Input 16 X0–XF
FPG-C32x (NPN)
Output 16 Y0–YF
Input 16 X0–XF
FPG-C28x (PNP)
Output 12 Y0–YB
Input 16 X0–XF
FPG-C24x (Relay)
Output 8 Y0–Y7
