Power LED blinking timing chart for the TH-42PD25U-P
Number of Times the Power LED Blinks
1 -
2 SOS2 (pin 12 SC20 on SC Board)
3 3.3V SOS (Pin 1 P25)
4 5V SOS (Pin 5 P25)
5 Power Supply SOS (Pin 7 of connector P27)
6 -
7 SOS1 (Scan Driver 2) pin 11 SC20 on SC Board)
8 -
9 SUS Driver pin9 SS23 (L719) “SS” Board)
10 -
11 -
12 Tuner Power
13 Fan SOS (pin 33 of PA2 (Cathode of D7546) on “PA” Board)
Table 6
