Power LED blinking timing chart for the TH-42PX25U-P
Number of Times the Power LED Blinks
1 -
2 SOS2 (TPSOS2 (L6604) on SC Board)
3 3.3V SOS
4 5V SOS
5 Power Supply SOS (Pin 7 of connector P27)
6 -
7 SOS1 (Scan Driver 2) TPSOS1 (L6603) on SC Board)
8 -
9 SUS Driver (TPSOS3 on “SS” Board)
10 -
11 -
12 Tuner Power
13 Fan SOS (Pin 6 of connector P27 on “P” Board)
Table 8
