17
VQT2M51
27 Status indicator (l 28)
28 Photoshot button [ ] (l 36)
29 Zoom lever [W/T] (In Motion Picture
Recording Mode or Still Picture
Recording Mode) (l 51)
Thumbnail display switch [ / ]/
Volume lever [sVOLr] (In Playback
Mode) (l 42)
30 DC input terminal (l 23)
≥ Do not use any other AC adaptors except
the supplied one.
31 Grip belt
1 Flip the belt.
2 Adjust the length.
3 Replace the belt.
2928
27
31
30
