Panasonic HDC-SD60K - [Hdc-Hs60]

18
VQT2M51
1 Power button [ ] (l 28)
2 Speaker
3 Intelligent auto/Manual button
[iA/MANUAL] (l 38)
4 Optical image stabilizer button
[ /O.I.S.] (l 52)
5 Mode switch (l 29)
6 Battery holder (l 22)
7 HDMI mini connector [HDMI]
(l 94, 97)
8 USB terminal [ ] (l 102, 117)
9 AV multi connector [AV MULTI]
(l 94, 108)
≥ Use the AV multi cable (only the supplied
cable).
10 SD card cover (l 27)
11 Card slot (l 27)
12 Access lamp [ACCESS] (l 27)
13 Lens cover
≥ The lens cover opens in Motion
Picture Recording Mode or Still
Picture Recording Mode. (l 29)
14 Internal stereo microphones
15 Built-in flash (l 57)
16 Lens
17 Video light (l 54, 73)
[HDC-HS60]
12 34
6
5
7 8 9
10
11
12
AV MULTI
13
14
16
15
17
