19
VQT2M51
18 LCD monitor (Touch screen) (l 30)
≥ It can open up to 90o.
≥ It can rotate up to 180o A towards the lens
or 90o B towards the opposite direction.
19 Recording start/stop button (l 34)
20 Sub recording start/stop button
(l 32)
≥ This button functions in the same manner
as the recording start/stop button.
21 Adjust zoom buttons (l 51)
22 Menu button [MENU] (l 43)
23 Video light button [LIGHT] (l 54)
24 Delete button [ ] (l 87)
25 Tripod receptacle
26 Battery release lever [BATTERY]
(l 22)
18 19
24
23222120
Due to limitations in LCD production
technology, there may be some tiny bright
or dark spots on the LCD monitor screen.
However, this is not a malfunction and
does not affect the recorded picture.
