18
VQT3K35
23 Status indicator (l 24)
24 Photoshot button [ ] (l 32)
25 Zoom lever [W/T] (In Motion Picture
Recording Mode or Still Picture
Recording Mode) (l 49)
Thumbnail display switch [ / ]/
Volume lever [sVOLr] (In Playback
Mode) (l 37)
26 Internal microphones
27 Mode switch (l 25)
28 Recording start/stop button (l 30)
29 Shoulder strap fixture
30 Grip belt
Adjust the length of the grip belt so that it fits
your hand.
1 Flip the belt.
2 Adjust the length.
3 Replace the belt.
31 DC input terminal [DC IN] (l 20)
≥ Do not use any other AC adaptors except
the supplied one.
262524
28
27
31
29 30
23
