21
VQT3K35
Charging and recording time
∫ Charging/Recording time
≥ Temperature: 25 oC (77 oF)/humidity: 60%RH
≥ These times are approximations.
≥ The indicated charging time is for when the battery has been discharged completely.
Charging time and recordable time vary depending on the usage conditions such as
high/low temperature.
≥ Recordable time of 3D recording mode is the same.
(During 3D recording mode, 1080/60p and iFrame recording mode cannot be used.)
≥ The actual recordable time refers to the recordable time when repeatedly starting/stopping
recording, turning the unit on/off, moving the zoom lever etc.
≥ The batteries heat up after use or charging. This is not a malfunction.
Battery model number
[Voltage/Capacity
(minimum)]
Charging
time
Recording
mode
Maximum
continuous
recordable time
Actual
recordable
time
Supplied battery/
VW-VBN130 (optional)
[7.2 V/1250 mAh]
2h30min
[1080/60p] 1 h 35 min
1h
[HA] 1h40min
[HG], [HX],
[HE]
1h45min
1h5min
[iFrame] 1h50min
VW-VBN260 (optional)
[7.2 V/2500 mAh]
4h30min
[1080/60p] 3h5min 1h55min
[HA]
3h20min
2h
[HG], [HX],
[HE]
2h5min
[iFrame] 3h30min 2h10min
Battery capacity indication
≥ The display changes as the battery capacity reduces.
####
If there is less than 3 minutes remaining, then will become red. If the battery
discharges, then will flash.
≥ The remaining battery capacity is displayed when using the Panasonic battery that you
can use for this unit. The actual time can vary depending on your actual use.
≥ When using the AC adaptor or batteries made by other companies, the remaining
battery capacity will not be shown.
