Panasonic KX-FL612CX - Operation Board Parts

Ref.
No.
Part No. Part Name & Description Remarks
R300 ERJ3GEYJ820 82
R301 ERJ3GEYJ820 82
R302 ERJ3GEYJ820 82
R303 ERJ3GEYJ822 8.2k
R304 ERJ3GEYJ222 2.2k
R305 ERJ3GEYJ473 47k
R308 ERJ3GEY0R00 0
R310 ERDS1TJ6R8 6.8 S
R312 ERJ3GEYJ681 680
R313 ERJ3GEYJ182 1.8k
R314 ERJ3GEYJ182 1.8k
R315 ERDS1VJ333 33k S
R316 ERJ3GEYJ103 10k
R317 ERJ3GEYJ563 56k
R318 ERJ3GEYJ103 10k
R319 ERJ3GEYJ563 56k
R320 ERJ3GEYJ100 10
R324 ERJ3GEYJ114 110k
R325 ERJ3GEYJ334 330k
R326 ERJ3GEYJ134 130k
R327 ERJ3GEYJ223 22k
R328 ERJ3GEYJ104 100k
R329 ERJ3GEYJ103 10k
R330 ERJ3GEYJ105 1M
R331 ERJ3GEYJ154 150k
R332 ERJ3GEYJ183 18k
R334 ERJ3GEYJ243 24k
R335 ERJ3GEYJ243 24k
R340 ERJ3GEYJ4R7 4.7
R341 ERJ3GEYJ101 100
R342 ERJ3GEYJ4R7 4.7
R343 ERJ3GEYJ102 1k
R344 ERJ3GEYJ103 10k
(RELAY)
RLY200 PFSL003Z RELAY S
(VARISTORS)
SA200 PQVDDSS301L VARISTOR (SURGE ABSORBER) S
SA201 PFRZ001Z VARISTOR (SURGE ABSORBER) S
ZNR200 ERZVA7D151 VARISTOR
ZNR71 PFRV271NS05K VARISTOR
(SWITCH)
SW200 PFSH1A011Z SWITCH
(TRANSFORMERS)
T201 PFLT8E003 TRANSFORMER S
T202 PFLT8E004 TRANSFORMER S
12.5. OPERATION BOARD PARTS
Ref.
No.
Part No. Part Name & Description Remarks
PCB3 PFWP2FL511M OPERATION BOARD ASS´Y (RTL)
PCB3-1 K0L1AA000001 SWITCH,SET
(ICs)
IC101 C1ZBZ0002089
(DIODES)
LED101 PQVDSLR325MC DIODE S
LED102 PQVDR325CA47 DIODE S
D101 1SS133 DIODE S
D102 1SS133 DIODE S
D103 1SS133 DIODE S
(CAPACITOS)
C103 ECEA1CK101 100 S
C104 ECUV1C104ZFV 0.1
C105 ECUV1C104ZFV 0.1
C106 ECUV1H103KBV 0.01
C110 ECUV1C104ZFV 0.1
C111 ECUV1C104ZFV 0.1
C112 ECEA1CKS100 10 S
C115 ECUV1H101JCV 100p
C117 ECUV1H101JCV 100p
C118 ECUV1H101JCV 100p
C119 ECUV1H103KBV 0.01
C120 ECUV1C104ZFV 0.1
Ref.
No.
Part No. Part Name & Description Remarks
C122 ECUV1C104ZFV 0.1
C125 ECUV1C104ZFV 0.1
C128 ECUV1H101JCV 100p
C129 ECUV1H101JCV 100p
C130 ECUV1H101JCV 100p
C132 ECEA1CK101 100 S
C133 ECUV1C104ZFV 0.1
C139 ECUV1C104ZFV 0.1
(LIQUID CRYSTAL DISPLAY)
CN101 L5DAAFB00001 LCD
(CONNECTOS)
CN102 PQJP8G43Y CONNECTOR,8P S
(PHOTO ELECTRIC TRANSDUCER)
PS101 CNA1006N PHOTO SENSOR
(RESISTORS)
J164 ERJ3GEY0R00 0
J165 ERJ3GEY0R00 0
J166 ERJ3GEY0R00 0
J167 ERJ3GEY0R00 0
R102 ERJ3GEYJ123 12k
R103 ERJ3GEYJ181 180
R104 ERJ3GEYJ123 12k
R105 ERJ3GEYJ181 180
R106 ERJ3GEYJ123 12k
R107 ERJ3GEYJ181 180
R110 ERJ3GEYJ181 180
R112 ERJ3GEYJ181 180
R113 ERJ3GEYJ181 180
R114 ERJ3GEYJ181 180
R115 ERJ3GEYJ181 180
R116 ERJ3GEYJ181 180
R117 ERJ3GEYJ181 180
R118 ERJ3GEYJ181 180
R119 ERJ3GEYJ563 56k
R120 ERJ3GEYJ331 330
R121 ERJ3GEYJ472 4.7k
R123 ERJ3GEYJ123 12k
R127 ERJ3GEYJ103 10k
R128 ERJ3GEYJ223 22k
R129 ERJ3GEY0R00 0
R130 ERJ3GEYJ101 100
R131 ERJ3GEYJ101 100
R133 ERJ3GEYJ122 1.2k
R134 ERJ3GEYJ101 100
R135 ERJ3GEYJ101 100
R138 ERJ3GEYJ331 330
R139 ERJ3GEYJ331 330
R146 ERJ3GEYJ101 100
R147 ERJ3GEYJ123 12k
R148 ERJ3GEYJ4R7 4.7
R149 ERJ3GEYJ123 12k
R152 ERJ3GEYJ181 180
(SWITCHES)
SW101 EVQ11Y05B SWITCH
SW102 EVQ11Y05B SWITCH
SW103 EVQ11Y05B SWITCH
SW104 EVQ11Y05B SWITCH
SW105 EVQ11Y05B SWITCH
SW106 EVQ11Y05B SWITCH
SW107 EVQ11Y05B SWITCH
SW108 EVQ11Y05B SWITCH
SW109 EVQ11Y05B SWITCH
SW110 EVQ11Y05B SWITCH
SW111 EVQ11Y05B SWITCH
SW112 EVQ11Y05B SWITCH
SW113 EVQ11Y05B SWITCH
SW114 EVQ11Y05B SWITCH
SW115 EVQ11Y05B SWITCH
SW116 EVQ11Y05B SWITCH
SW117 EVQ11Y05B SWITCH
SW118 EVQ11Y05B SWITCH
SW119 EVQ11Y05B SWITCH
SW120 EVQ11Y05B SWITCH
239
KX-FL612CX / KX-FL612CX-S
