Panasonic KX-FL612CX - Power Supply Board Components; 12.6 High Voltage Power Supply Board Parts

Ref.
No.
Part No. Part Name & Description Remarks
SW121 EVQ11Y05B SWITCH
SW122 EVQ11Y05B SWITCH
SW123 EVQ11Y05B SWITCH
SW124 EVQ11Y05B SWITCH
SW125 EVQ11Y05B SWITCH
SW126 EVQ11Y05B SWITCH
SW127 EVQ11Y05B SWITCH
SW128 EVQ11Y05B SWITCH
SW129 EVQ11Y05B SWITCH
SW130 EVQ11Y05B SWITCH
SW131 EVQ11Y05B SWITCH
SW132 EVQ11Y05B SWITCH
SW133 EVQ11Y05B SWITCH
SW134 EVQ11Y05B SWITCH
SW135 EVQ11Y05B SWITCH
SW136 EVQ11Y05B SWITCH
SW137 EVQ11Y05B SWITCH
SW138 EVQ11Y05B SWITCH
SW139 EVQ11Y05B SWITCH
SW140 EVQ11Y05B SWITCH
SW141 EVQ11Y05B SWITCH
SW142 EVQ11Y05B SWITCH
SW143 EVQ11Y05B SWITCH
SW144 EVQ11Y05B SWITCH
SW145 EVQ11Y05B SWITCH
SW146 K0L1AA000001 SWITCH
(THERMISTOR)
TH101 D4CC11030019 THERMISTOR
12.6. HIGH VOLTAGE POWER
SUPPLY BOARD PARTS
Ref.
No.
Part No. Part Name & Description Remarks
PCB4 EUKMBN889HA HIGH BOLTAGE POWER SUPPLY
BOARD ASS´Y (RTL)
(IC)
IC101 AN6742S IC
(TRANSISTORS)
Q101 2SB709A TRANSISTOR(SI)
Q102 2SB709A TRANSISTOR(SI)
Q103 2SD2137A TRANSISTOR(SI)
Q201 2SD2137A TRANSISTOR(SI)
Q202 2SA1699 TRANSISTOR(SI)
(DIODE)
D104 PFVDDHM3FJ60 DIODE(SI) S
D105 PFVDDHM3FJ60 DIODE(SI) S
D107 PFVDERA1504 DIODE(SI) S
D109 PFVDDHM3M20 DIODE(SI) S
D201 PFVDERA1504 DIODE(SI) S
D203 PFVDDHM3M20 DIODE(SI) S
D204 PFVDERA1504 DIODE(SI) S
D205 PFVDDHM3M20 DIODE(SI) S
ZD201 PFVDRD62ESAB ZENER DIODE S
ZD202 PFVDRD150EB ZENER DIODE S
(CONNECTOR)
CN2 PFJP06B01Z CONNECTOR,6P
(CAPACITORS)
C101 PFEUKMG1V470 47 S
C102 ECQV1H473JZ 0.047
C103 PFEUKMG1H2R2 2.2 S
C104 PFEUKMG1H010 1 S
C105 ECJ2VB1H103K 0.01
C108 ECJ2FB1H473K 0.047
C109 ECJ2VB1H153K 0.015
C110 ECKK3F471KBP 470p
C111 ECKK3D471KBB 470p
C112 ECKK3D471KBB 470p
C201 ECJ2FB1H473K 0.047
C202 ECJ2VB1H102K 0.001
C203 ECKK3D221KB 220p
C204 ECJ2VB1H103K 0.01
Ref.
No.
Part No. Part Name & Description Remarks
C205 ECKR2H102KB 0.001
C207 ECKK3D102KB 0.001
C209 ECKR2H101KB5 100p
(FUSE)
IP101 PFBAICPN38 FUSE S
(RESISTORS)
R101 PQ4R10XJ473 47k S
R102 ERDS2TJ104 100k
R104 ERDS2TJ103 10k
R105 ERJ6ENF2003 200k
R106 PQ4R10XJ103 10k S
R107 ERDS2TJ103 10k
R108 ERDS2TJ103 10k
R109 ERDS2TJ272 2.7k
R110 PQ4R10XJ103 10k S
R111 PQ4R10XJ103 10k S
R112 PQ4R10XJ103 10k S
R113 ERJ6ENF1004 1M
R114 PQ4R10XJ103 10k S
R116 PQ4R10XJ272 2.7k S
R117 PQ4R10XJ000 0 S
R118 PQ4R10XJ000 0 S
R119 PFRGH16A306N 30M S
R120 ERDS2TJ152 1.5k
R121 ERDS2TJ152 1.5k
R123 ER0S2TKF8451 8.45k
R124 ERJ6ENF1003 100k
R125 PQ4R10XJ000 0 S
R126 PQ4R10XJ102 1k S
R127 PFRGVR25J106 10M S
R202 ERJ6ENF4872 48.7k
R203 PQ4R10XJ102 1k S
R204 ERDS2TJ473 47k
R205 ERDS1TJ224 220k
R206 ER0S2TKF4532 45.3k S
R207 PFRGR25F1504 1.5M S
R208 PFRGVR25J105 1M S
R209 PFRGVR25J105 1M S
R210 ERDS2TJ333 33k
R211 PFRGR25F1005 10M S
R212 PFRGVR25J105 1M
R213 PFRGVR25J105 1M
R214 PFRGVR25J106 10M S
(SWITCH)
SW101 PFSEDE2LCJ33 SWITCH S
(COILS)
T101 ETB20DKA1 COIL
T201 ETB20DKD1 COIL
12.7. LOW VOLTAGE POWER
SUPPLY BOARD PARTS
Ref.
No.
Part No. Part Name & Description Remarks
PCB5 ETXKM450E5B LOW VOLTAGE POWER BORD ASS´Y
(RTL)
(ICs)
IC101 PFVIFA5317P IC S
IC201 PFVIPQ05RD11 IC S
(TRANSISTORS)
Q101 2SK2717 TRANSISTOR(SI)
Q201 2SC1740S TRANSISTOR(SI) S
(DIODES)
D101 PFVDLT1505 DIODE(SI) S
D102 PFVDLT1505 DIODE(SI) S
D103 PFVDLT1505 DIODE(SI) S
D104 PFVDLT1505 DIODE(SI) S
D105 PFVD05NU42 DIODE(SI) S
D106 PFVDERA9102 DIODE(SI) S
D108 PFVDERA9102 DIODE(SI) S
D109 PSVD10ELS4 DIODE(SI) S
D110 PFVDERA9102 DIODE(SI) S
240
KX-FL612CX / KX-FL612CX-S
