1. Introduction and Installation
10
For Fax Advantage assistance, call 1-800-435-7329.
Installation
1.5 Ink film
1.5.1 Installing the ink film
1 Open the front cover by pulling up the center
part.
2 Release the back cover by pushing the green
button (1).
3 Open the back cover.
4 Insert the front ink film roll by inserting its
blue gear (1) into the left slot of the unit (2).
Insert the rear ink film roll (3).
L The ink film is safe to touch, and will not
rub off on your hands like carbon paper.
L Make sure the blue gear (1) and white
gear (4) are installed as shown.
5 Turn the blue gear (1) in the direction of the
arrow until the ink film is tight (2).
1
3
4
1
2
1
2
FP145.book Page 10 Thursday, January 15, 2004 10:46 AM
