KX-FT21LA
4-4. SERVICE FUNCTION TABLE
Code Function Set Value
Effective Range
Default Remarks
501 Setting the pause time
001~600 X 100 msec
001~600
05000 msec
Selects the pause time in 100 msec
steps.
502
Setting the flash recall
time
01~99 X 10 msec 01~99 700 msec
Selects the line break time during
flashing in 10 msec steps.
503
Setting the pulse dial
speed
1:10pps
2:20pps
1, 2 10 pps Sets the pulse dial speed.
520
Setting the CED
frequency
1:2100Hz
2:1100Hz
1, 2 2100 Hz
When international communications
cannot be performed smoothly, select
1100 Hz.
521
Setting the international
line mode
1:ON 2:OFF 1, 2 ON
Selects the international line mode
during FAX communication.
522
Setting the return to
default mode
1:ON 2:OFF 1, 2 ON
Sets the resolution and contrast
conditions for FAX or copy to the
default settings.
523
Setting the reception
equalizer
1:ON
2:OFF
1, 2 OFF
When the telephone station is far from
the unit or sending cannot be
performed correctly, set to "ON".
524
Setting the sending
equalizer
1:ON
2:OFF
1, 2 OFF
When the telephone station is far from
the unit or sending cannot be
performed correctly, set to "ON".
544
Selecting the document
feed position
01~99 step 00~99 -----
When the ADF function is incorrect,
adjust the feed position. (8 step =
1mm)
550 Memory clear Press "START/COPY/SET".
551 Press "START/COPY/SET".
553
Setting the FAX monitor
function
1: OFF 2:PHASE
B 3:ALL
1, 2, 3 OFF
Sets whether to monitor the line
signal with the unit's speaker during
FAX communication or not.
554 Modem test Press "START".
555 Scanner test Press "START".
556 Motor test Press "START".
557 LED test Press "START".
558 LCD test Press "START".
559
Setting the document
jam detection
1:ON 2:OFF 1, 2 ON
See page 23.
561 KEY test Press any key.
570 Setting the % break
1:61%
2:67%
1, 2 61% Sets the % break of pulse dialing.
571
Setting the number of
times that ITS is
redialed
00~99 00~99 14 times
Selects the number of times that ITS
is redialed (not including the first dial).
572
Setting the ITS redial
interval
001~999 sec 001~999 030 sec Sets the interval of ITS redialing.
573
Setting of number of
time that
REMOTE TURN ON
BELL sound
01~99 01~99 15 times
Sets the number of times that the unit
starts to receive a document in the
TEL mode.
590
Setting the number of
FAX redial times
00~99 00~99 5 times
Selects the number of redial times
during FAX communication (not
including the first dial).
ROM version and sum check
