CIRCUIT OPERATIONS
- 151 -
KX-FT21LA
Varicap.
Anode
Cathode
Gerenal
Anode
Cathode
Zener
Anode
Cathode
LED
Anode
Cathode
Photo Diode
Anode
Cathode
• ¡ FOR THE SCHEMATIC DIAGRAM
1. DC voltage measurements are taken with an oscilloscope
or a tester with a ground .
2. The schematic diagram and circuit board may be
modified at any time with the development of new
technology.
Important safety notice
Components identified by a
mark have special characteristics
important for safety. When replacing any of these components,
use only the manufacturer's specified parts.
