22 CIRCUIT OPERATION (HANDSET)
22.1. Outline
Handset consists of the following ICs as shown in BLOCK DIAGRAM (HANDSET) (P.72).
· DECT BBIC (Base Band IC): IC1
−
− −
− All data signals (forming/analyzing ACK or CMD signal)
−
− −
− All interfaces (ex: Key, Detector Circuit, Charge, DC/DC Converter, EEPROM, LCD)
· RF Module: CN6
−
− −
− PLL Oscillator
−
− −
− Detector
−
− −
− Compress/Expander
−
− −
− Amplifier for transmission and reception
· AMP: IC2
−
− −
− Single OP_AMP for SP
· EEPROM: IC10
−
− −
− Temporary operating parameters (for RF, etc.)
Refer to EEPROM LAYOUT (HANDSET) (P.90).
· FLASH: IC11
−
− −
− Temporary image data
22.2. Power Supply Circuit/Reset Circuit
Circuit Operation:
When power on the Handset, the voltage is as follows;
BATTERY(2.2 V ~ 2.6 V: J1) → F1, L1, D1 → Q2 (1.8 V), Q3 (2.5 V), Q1 (4.0 V)
The Reset signal generates IC1 (120 pin) and 1.8 V.
22.3. Charge Circuit
Circuit Operation:
When charging the handset on the Base Unit, the charge current is as follows;
DC+(5.5V ~ 6V) → D1 → R3, R5 → CHARGE+(Base) → CHARGE+(Handset) → L4 → Q4 → D7→ F1 → BATTERY+ ...
Battery ... BATTERY- → R43 → GND → CHARGE-(Handset)→ CHARGE-(Base) → GND → DC-(GND)
In this way, the BBIC on Handset detects the fact that the battery is charged.
The charge current is controlled by switching Q5 of Handset.
Refer to Fig.101 in Power Supply Circuit (P.70).
22.4. Battery Low/Power Down Detector
Circuit Operation:
"Battery Low" and "Power Down" are detected by BBIC which check the voltage from battery.
The detected voltage is as follows;
· Battery Low
Battery voltage: V(Batt)
2.25V ± 50mV
The BBIC detects this level and "
" starts flashing.
· Power Down
Battery voltage: V(Batt)
2.00V ~ 2.05V
The BBIC detects this level and power down.
Refer to Check Point (Handset) (P.59).
22.5. Speakerphone
The hands-free loudspeaker at SP+ and SP- is used to generate the ring alarm. IC2 is used to switch off the telephone
loudspeaker and is used to amplify the signal to drive the hands-free loudspeaker. They are selected using the SP_AMP line
from pin 112 of the BBIC.
Refer to Troubleshooting for Speakerphone (P.62).
