Panasonic KX-TDA30

The SD Memory Card must be inserted before startup.
SD Memory Card
Slot Cover
SD Memory
Card
CAUTION
Do not remove the SD Memory
Card while power is supplied to the PBX. Doing so may cause the PBX to
fail to start when you try to restart the system.
2.3 Installing the Optional Service Cards
Slot Position
02
03
04
05
06
07
08
09
10
*
1
11*
1
01*
2
*1
Slots 10 and 11 accept only cards which do not have external ports. Therefore, these slots do not have removable cover plates.
*2
Slot 01 contains the pre-installed Super Hybrid Ports. No optional service card can be installed.
Slot Restrictions
The following table shows the slot restrictions. "ü" indicates that the slot supports the optional service card.
Card
Slot Number
Type Max 02 03 04 05 06 07 08 09 10 11
LCOT4 3
ü ü ü
LCOT2 3
ü ü ü
