Panasonic KX-TDA30

3. Insert the new extension bolt (included with the card) into the hole on the card, and tighten it to secure the
card.
Extension Bolt
2.4 Installing the Trunk Cards
LCOT2/LCOT4 Card
To trunk
RJ45
Example: LCOT4 Card
Accessories (included): Extension Bolt ´ 1, Strap ´ 1
User-supplied (not included): RJ45 connector (for LCOT2 card), or RJ45 connector or RJ11 connector (for
LCOT4 card)
*1
*1
The connector type may be RJ45 or RJ11 depending on the country/area.
Getting Started 15
2.4 Installing the Trunk Cards
