Panasonic KX-TDA50

7/17/2009 6
Revision 2
Note
Channels 5 through 8 are only available when the SIP-DSP4 card is mounted on the SIP-GW4
card.
3. Click the Reboot button that appears below the table after all the required configuration,
including the following SIP Telephony Basic Settings, is complete.
SIP Telephony Basic Settings
1-System Level Configuration:
This section describes system-wide configuration items that are generally required for
each KX-TDA50 to work with Cbeyond.
*Operation MenuÆ1.2 SIP settingsÆ1.2.1 Channel and SIP Telephony
Step Command Purpose
Step 1
Set Proxy Server<compulsory>.
(i.e. Sip-proxy.dal0.cbeyond.net)
Set the TDA50 SIP server to the
Fully Qualified Domain Name
(FQDN) for the Cbeyond
Application Server cluster.
The domain must match the domain
configured for the Cbeyond
subscriber’s line/port domain.
Step 2
Enable Registration.
Specifies whether to register on the
SIP server or not (if required).
Step 3
Set Registration Timer (Offer).
Specifies the length of time that
the card offers for
Registration to the SIP server (if
required).
Step 4
Set Register Server.
Specifies the domain name or IP
address of a Registrar server (if
provided). If an ITSP provides both
Proxy and Registrar Server
information, specify the Registrar
Server information.
Step 5
Set Domain name.
(i.e.sipconnect.dal0.cbeyond.net)
Specifies the domain name (if
provided besides proxy and registrar
server).
Step 6
Set ITSP Name.
Specifies the ITSP name (optional).
